Surface-mounted light fixture SPINALED

LEDrectangularlinear

Overview
SPINAled is the continuation of the classic SPINA collection, refined for modern LED technology. Designed for architectural applications, it is offered as ceiling-mounted and pendant luminaires with opal acrylic diffuser, and as variants with linear lens or dot matrix for enhanced glare control.

Product highlights

• Design: Daniel Kübler / Erwin Egli
• Slim pendant suspension with a purist aesthetic
• Modular options and reduced form for discreet, versatile lighting
• Dot matrix option available for optimized glare control
• Selectable surface finishes and versions with or without external control gear

Variants & Sizes

• Ceiling-mounted luminaires with opal acrylic diffuser, diameter/length range: 600–1500 mm
• Ceiling-mounted luminaires with opal acrylic diffuser, external control gear version
• Pendant luminaires with opal acrylic diffuser, length range: 1200–1500 mm
• Pendant luminaires with linear lens, length range: 1200–1500 mm (60° beam)
• Versions with opal diffuser plus dot matrix (600–1500 mm)

Application & Behavior

• Suitable for a wide range of architectural and interior applications thanks to homogeneous light distribution, high colour rendering and good glare control
• Surface-mounted version with external control gear is splash-proof and suitable for wet rooms and rain-protected outdoor areas (IP54 variants)

Lighting effect

• Opal acrylic diffuser: soft, uniform, wide-beam light distribution suitable for general lighting tasks (UGR ≤28)
• Linear lens variant: high brilliance and well-defined shadows, ideal for material accentuation (60° beam, UGR ≤22)

Selectable color / finish options

• Natural anodised
• Chrome polished
• Versions with external control gear in matching finishes

Technical specifications

• Mounting: Ceiling or wall mounting; pendant versions supplied for ceiling mounting with two nickel-plated steel-cable suspensions (length 2500 mm), continuously adjustable height, two cable holders, transparent cable 2 x 0.35 mm²
• Housing: Extruded aluminium (mat anodised for pendant with passive cooling in specific versions)
• Optics: Opal acrylic diffuser; UGR ≤28 for opal variants; opal with dot matrix available; linear lens variant Δ 60°, UGR ≤22
• Lamps: Integrated LEDs, CRI >90; colour temperatures: 2700 K, 3000 K or 4000 K
• Service life: 50'000 h L90 B10 (Ta 25° C)
• Control gear: PS 230 V / 50 Hz (standard); EVG 230 V / 50 Hz (order separately) for certain versions; some pendant versions: PS 230 V / 50 Hz in a separate housing
• Protection class: I (standard versions) / III (external-control-gear versions where indicated)
• Ingress protection: IP 20 (standard mounted/pendant); IP 54 for surface-mounted version with external control gear (splash-proof)
• Energy efficiency class: D
• Glare / distribution: UGR values indicated per variant (UGR ≤28 for opal diffuser; UGR ≤22 for linear lens); dot matrix available for improved glare control
