Minimalist design ceiling light KIVO

roundcircularaluminum

Overview
The KIVO ceiling lamp delivers glare-controlled, high-quality lighting for reception areas, offices and public interiors. Its minimalist appearance and modular shade system make it suitable as an elegant lobby luminaires or as ergonomic workplace lighting.

Product highlights

• Design: RIBAG Design Studio — optimized light distribution and high visual comfort.
• Glass lens optics producing brilliant light with high colour rendering (CRI >90).
• Customisation: three housing colours, two sizes (Ø 140 mm and Ø 270 mm) and magnet-mounted interchangeable shades.
• Precise glare control with well-defined light cones for visual comfort (UGR ≤16 on applicable variants).
• Tunable white option (Ø 140 mm) from 2200 K to 5000 K for mood and task lighting.

Optical data
Ceiling lamp Ø 140 mm: direct beam 60°
Ceiling lamp Ø 270 mm: direct beam 70°

Interchangeable shades (examples)

• Shade golden brown anodized
• Shade champagne anodized
• Wood shade oak
• Wood shade black walnut
• Shade rosé gold
• Shade sand gold

Videos / Demonstrations
Video showing interchangeable-shade mounting and change procedure (magnet mounting).

Technical specifications

• Model / family: KIVO
• Sizes: Ø 140 mm and Ø 270 mm
• Mounting: ceiling mounting; Ø 140 mm AC variant: connection to 230 V AC / 50 Hz mains, dimmable via LED phase dimmer
• Lamp housing: die-cast aluminium
• Optics: high-quality glass lens technology; interchangeable shades ordered separately; UGR ≤16 (some configurations ≤19)
• Lamps / Light source: integrated LED, CRI >90; standard colour temperatures 2700 K or 3000 K (4000 K on request); Ø 140 mm tunable white variant 2200 K–5000 K
• Service life: 50,000 h L90 B10 (Ta 25 °C)
• Protection class: I
• Ingress protection: IP 43
• Energy efficiency class: Ø 140 mm (AC 230V) – F; Ø 140 mm (external control gear) – D; Ø 270 mm – D (depending on configuration)
• Control gear (variant information): external control gear uses EB 230 V/50 Hz constant current 350 mA (ordered separately); Ø 270 mm variant uses PS 230 V/50 Hz
• Glare / light distribution: clearly defined light cones; examples: direct beam angles 60° (Ø 140 mm) and 70° (Ø 270 mm)
• Interchangeable shades: magnet-mounted for easy exchange; finishes: anodized metal, wood veneers, metallic tones
