Contemporary ceiling light VIOR

roundPMMAcast aluminum

Overview
The ceiling lamp VIOR combines brilliant direct light with ceiling-brightening indirect light, creating a pleasant and distinctive atmosphere. Its compact, sensual shape integrates seamlessly into contemporary interiors and supports architectural accents. A smaller VIOR version is available as a high-voltage variant for direct connection to existing 230 V installations.

Product highlights
Designed by RIBAG Design Studio to combine two lighting moods—brilliant direct light and ceiling-brightening indirect light—using a single LED and precise light control.

Technology and optics
In collaboration with Bartenbach, VIOR uses a patented optical system with primary and secondary lenses and microreflectors to deliver pinpoint-directed light and excellent glare control. The integrated light source is flicker-free with high color rendering. Optics achieve UGR ≤ 16 for good visual comfort.

Splash water protection
Protection rating IP54 permits use in indoor wet zones.

Light quality and tunable white
High-quality LEDs provide excellent color rendering (CRI > 90). Tunable white versions span 2200 K to 5000 K to create atmospheres from warm candlelight to cool workplace lighting while maintaining high color fidelity across intensities.

Selectable colour variants

• black
• white
• sand gold
• rosé gold

Awards
Design awards recognition (examples shown: where applicable, e.g. Red Dot).

Available product variants

• Ceiling luminaires (external control gear) — ceiling mounting with external control gear (order separately), suitable for embedded housing Kaiser Halox-O No.1281-30
• Ceiling luminaires (AC 230V) — ceiling mounting for direct connection to 230 V AC / 50 Hz mains, dimmable via LED phase dimmer

Notes on installation and design flexibility
Die-cast aluminium housing with synthetic PMMA glass. Simple and reliable ceiling mounting. Multiple finishes available to match interior designs.

Technical specifications

• Mounting: ceiling mounting with external control gear (order separately) — suitable for embedded housing Kaiser Halox-O No.1281-30; AC variant for direct 230 V connection and phase-dimmable
• Housing: die-cast aluminium, synthetic glass (PMMA)
• Optics: patented lens / microreflector technology; UGR ≤ 16
• Light source: integrated LED, CRI > 90; 2700 K or 3000 K (4000 K on request)
• Service life: 50,000 h L90 B10 (Ta 25° C)
• Control gear (external variant): PSU 230 V / 50 Hz, constant current 350 mA (order separately)
• Control gear (AC variant): operates without external driver (direct 230 V), dimmable via LED phase dimmer
• Protection class: Class III (external driver variant) / Class I (AC 230 V variant)
• Ingress protection: IP54 (indoor)
• Energy class: D (external driver variant) / F (AC 230 V variant)
• Glare control: optimized for visual comfort
• Finish options: multiple selectable finishes (examples: black, white, sand gold, rosé gold)
