Recessed downlight MILUM

for ceilingpendantLED

Overview
The MILUM downlight is a miniaturized, modular ceiling luminaire designed for precise architectural lighting. Available in multiple module lengths and beam angles, it integrates with Lightline and Wallwasher modules to support flexible lighting concepts for high‑end residential and commercial projects.

Design
MILUM features refined workmanship and a consistent design language using high‑quality materials. Its compact profile allows discreet installation while offering configurability for tailored lighting schemes.

Technology and light quality

• Advanced components optimize performance in a very small form factor.
• Optics: light exit set back in the slim profile for effective glare control; UGR values specified per module.
• High visual comfort and luminous efficacy: bright light with excellent colour rendering for both downlight and wallwasher modules.
• Tunable White option: adjustable from 2200 K to 5000 K for flexible mood and task lighting.

Selectable colour variations
Ceiling finishes: natural anodized, black RAL 9005 and white RAL 9003 to match architectural interiors.

Applications / Configurations
The system is modular: delivered as recessed downlights and pendant variants; module lengths (e.g. 4‑module 600 mm, 8‑module 900 mm) and combinations with Lightline and Wallwasher enable varied lighting strategies.

Technical specifications

• Mounting: tool‑free installation on mounting rail (mounting rail ordered separately).
• Housing: extruded aluminium.
• Optics: high‑quality lens technology; UGR ≤19 (60°) / ≤10 (30°).
• Light source: CRI >90, SDCM 2; colour temperatures 2700 K, 3000 K or Tunable White 2200–5000 K; integrated LEDs.
• Service life: 50,700 h L90 B10 (Ta 25°C).
• Control gear: PS 230 V / 50 Hz.
• Protective class: Class I.
• Protection rating: IP20.
• Energy class: F.
