Minimalist design ceiling light VIOR BOLD

roundPMMAcast aluminum

Overview
The VIOR bold ceiling luminaire combines a narrow, brilliant direct beam from a single LED with a soft indirect ceiling wash. Its patented optics deliver high visual comfort and precise glare control, making it suitable for offices, educational facilities and architecture-focused interiors where clear task lighting and pleasant ambient illumination are required.

Product highlights

• Design: Developed by RIBAG Design Studio to integrate two lighting moods with one LED — focused direct light and space-enhancing indirect light; minimalist, timeless aesthetic.
• Patented lighting technology: In cooperation with Bartenbach; primary and secondary lenses plus a micro-reflector ensure accurate light distribution and effective glare control.
• Microfacet reflector: 4096 microfacets direct light uniformly to the ceiling, providing high luminous intensity with controlled distribution and excellent color rendering.
• Plug & Play: Tool-free plug-in connection to the control gear; available with multiple dimming options and an optional emergency variant.
• High color rendering and output: CRI >90 and high lumen efficacy for demanding lighting concepts.
• Color variants: Two finish options for integration with interior design.

Lighting effect
Narrow-beam direct light combined with gentle indirect ceiling illumination enhances spatial perception and emphasizes architectural elements while maintaining visual comfort for occupants.

Awards

• The VIOR family has received design awards (e.g. Red Dot).

Technical specifications

• Mounting: Tool-free mounting to the separate control gear unit (ordered separately).
• Housing: Die-cast aluminium; synthetic glass PMMA.
• Optics: Patented lens and microreflector technology; UGR ≤16.
• Lamps: CRI >90; colour temperatures: 2700 K, 3000 K or 4000 K.
• Service life: 50'000 h L90 B10 (Ta 25 °C).
• Control gear: EVG 230 V / 50 Hz (order separately).
• Protection class: I.
• Ingress protection: IP54.
• Energy efficiency class: D.
