Surface mounted spotlight SPARK

conicaltubularIP54

Overview
Whether new construction or renovation, the ceiling lamp with integrated control gear can be mounted in the simplest way, without any required cavity ceiling. With IP 54 it is ideally suited for wet zones and protected outdoor areas. It features proven lighting technology and excellent lighting effect. The slightly conical ceiling lamp is available in three housing colours with four different beam angles, each as Single Color or Tunable White variant.

Design
Design: RIBAG Design Studio. Minimalist design delivering lighting comfort and high functionality. High-precision reflectors developed by Bartenbach Lichtlabor ensure very good glare control and highly precise light control suitable for demanding professional lighting tasks as well as residential and commercial applications.

Splash water protection
Integrated cover glass and IP 54 rating make SPARK suitable for wet areas and covered outdoor areas in addition to indoor use.

Easiest assembly
Installation is simple for new construction and renovation, requiring no cavity. A drilling template is included in the package and a membrane for ceiling IP 54 protection is provided to ensure easy installation.

Three colour variants

• Black
• White
• Grey

Four light distributions with precise cut-off

• 16° (spot)
• 30° (spot)
• 50° (flood)
• 70° (wide flood)

Lighting quality
Brilliant light with high colour rendering and excellent visual comfort through cleanly delineated light cones and effective glare control. High-quality LEDs with CRI >90 and SDCM2; Tunable White option provides 2200 K – 5000 K (also available in fixed 2700 K or 3000 K).

System and application
Consistent system concept for ambient lighting, accent lighting and precise wall illumination. Efficient and durable with proven lighting components and reflectors tuned for high performance.

Technical specifications

• Mounting: For mounting on the ceiling
• Lamp housing: Diecast aluminium
• Optics: High-precision Bartenbach reflectors (16°, 30°, 50° or 70°)
• Lamps: CRI >90, SDCM2; 2700 K, 3000 K or Tunable White 2200 K – 5000 K; integrated LEDs
• Service life: 50'7000h L90 B10 (Ta 25° C)
• Control gear: PS 230 V / 50 Hz (integrated)
• Lamp protection class: I
• Protection level: IP 54
• Energy efficiency class: D
• Glare control / UGR: very good (system designed for low glare)
