Wall-mounted air conditioner AC100BNTPKG/EU

split systemcommercialreversible

Overview
Designed for commercial applications, this wall-mounted split system provides combined cooling and heating with capacities suitable for small to medium-sized businesses such as restaurants, retail spaces and offices. The system supports one indoor unit and scalable outdoor combinations to maintain consistent comfort throughout the operating day.

Key features

• Quiet mode: whisper-quiet operation for peaceful and undisturbed environments, suitable for offices and other noise-sensitive spaces.
• Large capacity: cooling capacities up to 12.10 kW across available configurations to serve larger rooms and open-plan areas.
• Motorized shutter: vertical sweeping motorized shutter for precise airflow distribution and improved occupant comfort.
• Heating performance: CAC HEE Outdoor Unit engineered to deliver 100% heating performance down to -25 °C (note: 14 kW variant excluded; 14 kW achieves 100% at -10 °C).

Smart features

• Smart Control: compatible with the SmartThings App for remote operation (on/off, mode selection, scheduling and energy monitoring).
• WiFi Kit supported: enables network connectivity for smart control and monitoring.
• SolarCell Remote Controller: remote with integrated solar panel charging (reduces disposable battery use) and USB-C port for fast charging.

Compatibility & model

• Commercial model designation: AC100BNTPKG/EU
• Compatible indoor/outdoor combinations: Indoor Unit AC100BNTPKG/EU; Outdoor Unit AC100BXAPKG/EU and AC100BXAPNG/EU
• Available capacity on page: 10.0KW (page selection)
• Available power / phase: 1 Phase

Technical specifications

• Type: EU-10.0kW-RAC-1
• System / Mode: Heat Pump
• Capacity (Cooling) [kW]: 3.60 / 9.50 / 12.10 kW
• Capacity (Heating) [kW]: 2.90 / 10.80 / 16.20 kW
• Power Input (Cooling) [kW]: 0.78 / 2.74 / 4.20 kW
• Power Input (Heating) [kW]: 0.65 / 3.45 / 6.40 kW
• Current Input (Cooling) [A]: 4.0 / 12.3 / 18.3 A
• Current Input (Heating) [A]: 4.0 / 15.3 / 27.9 A
• MCA: 29.0 A
• MFA: 35.0 A
• Energy Efficiency - Cooling: SEER 6.9 (A++)
• Energy Efficiency - Heating: SCOP 4.1 (A+)
• Piping connections: Liquid Pipe (Ø): 9.52 mm; Gas Pipe (Ø): 15.88 mm
• Installation maximum length: 85 m
• Installation maximum height: 30 m
• Field wiring - Transmission Cable: 0.75 ㎟
• Refrigerant type: R32 (Contains fluorinated greenhouse gases, GWP = 675)
• Factory charging (kg): 3.50 kg
• Factory charging (tCO2e): 2.36 tCO2e
• Control method: EEV
• Power Supply (Indoor Unit) [Φ, #, V, Hz]: 1, 2, 220-240, 50
• Power Supply (Outdoor Unit) [Φ, #, V, Hz]: 1, 2, 220-240, 50
• Fan (Indoor Unit) type: Cross Flow
• Air Flow Rate (Indoor) [m3/min]: (C)22.7 / 19.8 / 17.8 (H)24.0 / 21.3 / 19.2 CMM
• Fan motor (output): 58 W
• Number of indoor unit: 1 EA
• Drain pipe (Ø): ID18mm Hose
• Sound Pressure Level (Indoor) [dB(A)]: 49 / 46 / 43 / 37 dBA
• Sound Power Level (Indoor Cooling) [dB(A)]: 65 dBA
• Outdoor Air Flow Rate (Cooling) [m3/min]: 125 CMM
• Sound Pressure (Outdoor) [dB(A)]: Cooling / Heating = 47 / 50 dBA
• Sound Power Level (Outdoor Cooling) [dB(A)]: 66 dBA
• Indoor Unit Net Weight: 18.5 kg
• Indoor Unit Net Dimensions (WxHxD): 1280 x 345 x 253 mm
• Outdoor Unit Net Weight: 100.0 kg
• Outdoor Unit Net Dimensions (WxHxD): 940 x 1420 x 330 mm
• Operating Temperature Range - Cooling: -20 ~ 52 ℃
• Operating Temperature Range - Heating: -25 ~ 24 ℃
• Smart - WiFi Kit: Yes
• App Connectivity: SmartThings App Support: Yes
