Technical information
Générales
-Smoke outlet : Ø200 mm
-Weight : 155 kg version de base
-Size logs : jusqu'à 55 cm
-In compliance with : EN 13229
-Size : 71 cm
Régulation manuelle
-Nominal output : 9,5 kW
-Maximum output : 19 kW (indicatif)
-CO Rate : 0,110%
-Particles emission (mg/Nm3) : 31 mg/Nm3
-Efficiency : 75,3 %
- Damper: with adjustable sealing - Swing-door: the door is blocked when the damper is closed - Lift door : the damper automatically opens at the door opening.
Options : - Lift door - Convector - Air distribution (double combustion included) - Adapter for double combustion connection Ref : A0210 - Adapter for air distribution connection Ref : A0211
