Technical information
Générales
Smoke outlet : Ø200 mm
Weight : 195 kg
Size logs : jusqu'à 45 cm
In compliance with : EN 13229
Size : 71 cm
Régulation manuelle
Nominal output : 11 kW
CO Rate : 0,06%
Particles emission (mg/Nm3) : 32 mg/Nm3
Efficiency : 77,4%
- Damper: with adjustable sealing - Swing-door: the door is blocked when the damper is closed - Lift door : the damper automatically opens at the door opening.
Options : - Lift door - Convector - Air distribution (double combustion included) - Adapter for double combustion connection Ref : A0210 - Adapter for air distribution connection Ref : A0211
