Aluminum solar shading

for facade

DescriptionBrise soleil type sunbreaker system with fixed, discontinuous aluminium blades. Extruded, tubular aluminium blades, in one single extruded piece, with elliptical format for sunbreaker or airfoil sunshade systems with discontinuous blades.The fixing system of the blades is via aluminium end plugs, with different degrees of orientation, thus achieving a blade system with visible transoms.The Tamiluz sunbreaker range has all transom profiles, plugs and accessories for top quality fitting. System specificationsExtruded aluminium blades. 6060-T5 alloy (T6 optional)Extruded aluminium transoms. 6063-T5 alloyAluminium plugsMultiple blade orientationHorizontal or vertical bladesVariable distance between bladesMaximum distance between blade supports: 4300mm ModelsElliptical format, 6 models from 150 to 400 mm ApplicationsBrise soleil SunbreakersScreen louvresAirfoil sunshadesCanopies and pergolasSunscreens FinishesRAL chart lacquer (gloss or matt) or textured. Qualicoat sealAnodised. Qualanod seal.
