Metal sliding system SMARTIA M14400

glasspationon-insulated

SMARTIA M14400 is a non-thermal sliding system, designed to offer simplicity, ease of use, and flexibility in fabrication. Thanks to its smart design, it provides a wide variety of solutions, high functionality, and a competitive price-quality ratio.<br><br>Advantages<br><br>• Basic system’s depth 32mm.<br>• Smooth and easy gliding and long-term functionality thanks to inox rails.<br>• Easy access with low threshold, ideal for renovations.<br>• Reliable choice for regions with warm climate.<br>• Smart design that supports various typologies with just a few profiles and common accessories.<br><br>Generic<br><br>THERMAL INSULATION<br>No<br><br>EXTERIOR SHAPE<br>Flat<br><br>Technical Characteristics<br><br>FRAME DEPTH<br>79 mm<br><br>SASH DEPTH<br>32 mm<br><br>MINIMUM VISIBLE ALUMINIUM FACE HEIGHT<br>99,5 mm<br><br>MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE)<br>76,4 mm<br><br>GLAZING TYPE<br>Single - Double<br><br>MAXIMUM GLAZING THICKNESS<br>20 mm<br><br>MECHANISM<br>Sliding mechanism<br><br>SEALING METHOD<br>Perimetrical with simple brushes<br><br>MINIMUM THRESHOLD HEIGHT<br>31 mm<br><br>Characteristics<br><br>TYPES OF TYPOLOGY<br>Horizontal sliding sashes, Meeting stile<br><br>SASH WEIGHT<br>up to 180 Kg sliding<br><br>
