Aluminum sliding system COMFORT M9050

windownon-insulatedhome

Product overview
COMFORT M9050 is a non-insulated sliding aluminium system characterized by low weight and curved profile geometry, designed for small to medium spans in residential and light-commercial façades.

Advantages

• Cost-effective solution for small to medium openings
• Low-profile, lightweight components suitable for slim sightlines
• Flexible configurations for different installation types

Certificates
TÜV Austria OK Recycled (product certificate)

Generic
WINDOW TYPE: Sliding
THERMAL INSULATION: No
EXTERIOR SHAPE: Curved

Technical Characteristics
SASH DEPTH: 32 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT: 85.5 mm
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE): 79 mm
GLAZING TYPE: Single - Double
MAXIMUM GLAZING THICKNESS: from 4 mm up to 20 mm
MECHANISM: Sliding mechanism
SEALING METHOD: Perimetrical with hi-fin gaskets

Performance
WATER TIGHTNESS: CLASS 2B
AIR PERMEABILITY: CLASS 4

Characteristics
TYPES OF TYPOLOGY: Double and triple horizontal sliding sashes; Meeting stile; Pocket typologies; Combined with fly-screen and shutter
SASH WEIGHT: up to 90 Kg

Available typologies (examples)

• Double horizontal sliding sash
• Double horizontal parallel sliding window with rolling shutter
• Double horizontal parallel sliding window with fixed fanlight
• Four horizontal sliding sashes with meeting stile
• Triple horizontal sliding sash
• Double sliding sash with fixed light
• Double pocket horizontal sliding window with fly-screen & shutter
• Single horizontal sliding pocket sash with fly-screen and shutter

Characteristics / Technical specifications

• Model: COMFORT M9050
• Type: Non-insulated sliding aluminium system
• Sash depth: 32 mm
• Minimum visible aluminium face height: 85.5 mm
• Minimum visible aluminium face width at central vertical column: 79 mm
• Glazing type: Single or Double
• Maximum glazing thickness: 4 mm – 20 mm
• Mechanism: Sliding
• Sealing: Perimetrical with hi-fin gaskets
• Water tightness: Class 2B
• Air permeability: Class 4
• Maximum sash weight: up to 90 Kg
