Wall-mounted pergola ST-100-KS-KD

self-supportingaluminumsteel

Product overview
A reinforced steel pergola designed for outdoor kitchens, wider grill islands and custom cooking zones. The ST-100-KS-KD features an aluminum middle post and middle beam to support larger spans and heavier loads.

Key features

• Reinforced configuration for wider cooking layouts
• Aluminum middle post: 100 x 100 mm
• Aluminum middle beam support: 150 x 96 mm
• Side beam: 150 x 35 mm
• Adjustable louver roof: 180 x 34.5 mm
• Load capacity: 60 kg/m²+
• Standard sizes: 3 x 5 m and 3 x 6 m (typical height 2.4 m)
• Water gutter: 32 x 56 mm
• LED strip options: warm white, white, RGB
• Roof rotation / louver angle control: up to 120°

Technical data (table)
Model: ST-100-KS-KD
Post: 100 x 100 mm
Middle Post: Aluminum 100 x 100 mm
Side Beam: 150 x 35 mm
Middle Beam: Aluminum 150 x 96 mm
Water Gutter: 32 x 56 mm
Louver Roof: 180 x 34.5 mm
Available Sizes: 3 x 5 x 2.4 m / 3 x 6 x 2.4 m
Load Capacity: 60 kg/m²+
LED Strips: Warm white / white / RGB option
Product Position: Outdoor kitchen / wider custom cooking zone

Use cases

• Outdoor kitchens and wider grill islands
• Patio kitchens and backyard cooking zones
• Restaurant and hospitality outdoor cooking and serving counters
• Freestanding kitchen pavilions or wall-adjacent installations

Configuration & accessories

• LED louver lighting (warm white / white / RGB)
• Zip blind (manual or motorized) for side shade and wind reduction
• Sliding shutters and fixed slat walls for side screening
• Adjustable louver wall for airflow and privacy control
• Glass sliding doors or folding glass doors for premium enclosures
• Color options: Light Neutral, Graphite Grey, Dark Charcoal

Installation
Can be installed wall-adjacent or as a freestanding four-post pavilion depending on layout, access and service direction.

Technical specifications

• Model: ST-100-KS-KD
• Post: 100 x 100 mm
• Middle post: Aluminum 100 x 100 mm
• Side beam: 150 x 35 mm
• Middle beam: Aluminum 150 x 96 mm (reinforced middle beam support)
• Louver roof: 180 x 34.5 mm (adjustable up to 120°)
• Water gutter dimensions: 32 x 56 mm
• Standard sizes: 3 x 5 x 2.4 m and 3 x 6 x 2.4 m
• Load capacity: 60 kg/m²+
• LED lighting: Warm white / white / RGB options
• Typical applications: outdoor kitchen, grill pergola, patio kitchen, restaurant cooking/dining zones
• Available side options: zip blinds, sliding shutters, fixed slat walls, adjustable louver walls, glass sliding/folding doors
