Its dimensions are compact and its internal space is well organized thanks to adjustable shelves and bottle holders or sliding drawers. It is available with small (in model AC) freezing compartment, with internal or external compressor.
Freezer (-10°C -20°C) with internal compressor.
Internal walls in stainless steel 304BA, external front and door in
The refrigerating unit with forced air-cooled compressor
12/24Vdc or 110Vac 60Hz or 220Vac 50 Hz.
Customizable with several options.
- W480xD507xH620 capacity of the freezer 45Lt;
- Range of temperature from -10°C to -20°C;
- External plasticized galvanized metal sheet;
- Internal walls in polished stainless steel 304BA;
- External front and door in stainless steel 316SB;
- Polyurethane foam insulation thickness 60mm;
- Condensate drainage connected by ¼ coupling;
- No. 01 fixed stainless steel shelf;
- No. 01 stainless steel shelves adjustable in high;
- Gas expansion by capillary pipe;
- Mechanical thermostat for temperature control;
- Internal compressor forced air cooled;
- Do not place the refrigerator directly to atmospheric agents,
but cover it with proper protections.
Sliding mechanism which replaces the handle in the case
of a fully built-in installation with an exterior cabinet door.
Special stainless steel frame which allows to
easily fix the cupboard to the forniture.
Special drawers complete with racks and locking device
No.Max drawers: 01
Net using space drawers:
1 drawer W305xP335xH280
In order to keep the internal temperature under
control and have real time indications of fridge
In order to pull out the drawers, is necessary that the door is opened
at least 100°
