Power socket PP-EU-13B

electricwall-mountedbuilt-in

Short description
Ready-to-fit 2P+E Schuko (Type F) power socket by Livolo, reference PP-EU-13B. Rated 16 A with earthing, push-in terminal connection and a gloss white tempered glass 1-gang faceplate supplied.

Overview
Modernise industrial and commercial electrical installations with this complete Livolo Schuko socket kit. Supplied with mechanism, metal mounting frame and a gloss white tempered glass faceplate, this 2P+E Type F socket provides a 16 A rated current and integrated earthing for safe powering of equipment. The push-in terminal system accelerates wiring and reduces installation time. Built-in child protection increases on-site safety. The tempered glass faceplate resists scratches and discolouration, offering a premium finish suited to renovation and new-build projects.

Product highlights

• Complete ready-to-install Schuko socket kit
• 2P+E Type F socket, rated 16 A
• Push-in terminal quick connections
• Integrated child protection shutters
• Gloss white tempered glass faceplate
• Metal mounting frame included
• Designed for fast installation
• Compatible with standard European installations
• Clean, modern premium design

Pack contents

• 1 x Schuko earthed socket - Type F, white (ref. EU-11)
• 1 x 1-gang glass faceplate - white, gloss (ref. A-SR-11B)

Installation & compatibility

• Fits round or square back boxes ≥ 40 mm
• Suitable for horizontal or vertical mounting
• For standard electrical installations (Live / Neutral / Earth)
• Compatible with common European wiring configurations

Pair it with

• 2P+E Schuko 16 A Type F socket mechanism
• SR series 1-gang glass faceplate
• Metal mounting bracket
• Installation guide

Technical specifications

• Manufacturer: Livolo
• Reference: PP-EU-13B
• Connection: Push-in terminals
• Certification: CE & RoHS
• Socket type: Europe (Type F)
• Format: 1 gang
• Material: Tempered glass faceplate
• Child protection: Yes
• Earthing: Yes
• Series: SR
• Categories: Power socket, Ready-to-fit products
• Function: Ready-to-fit Schuko Type F socket
• Weight: 0.146 kg
• Rated current: 16 A
