Electric bratt pan FUTURA HD 200

for commercial kitchen

Description
The Metos Futura HD 200 L bratt pan is built for large-capacity professional kitchens and continuous use. It stands on two robust legs for stability and must be fixed to the floor. Motorised tilting, simple cleaning access and integrated safety protections make operation efficient and safe.

Key features

• Two independently adjustable frying zones (50 °C – 250 °C)
• Balanced, insulated cover
• Continuous, seamless stainless-steel cooking surface
• Stainless-steel frame and structure
• Elevated control panel located in the right leg
• Electromechanical control
• Emergency stop switch
• Overheating protection

Options and accessories

• Options (ordered separately): hand shower
• Options (ordered separately): water filling tap
• Accessories: strainer plate

Technical specifications

• Weight: 370.0 kg
• Overall dimensions: 1858 × 948 × 1786 mm
• Capacity: 200 litres
• Frying area: 0.78 m²
• Depth: 273 mm
• Number of GN1/1 containers (fits): 4
• Temperature range: 50 °C – 250 °C
• Heating: aluminium core surrounded by heating elements for rapid heating
• Insulation: double walls
• Tilting: motorised; tilt for emptying 68°; maximum tilt 90°; tilting disabled when lid is on or when filling with water
• Pouring spout distance to floor (at 68°): 570 mm
• Control: electromechanical; elevated control panel located in the right foot
• Electrical connection: 400/230 V, 63 A, 41.4 kW, 3NPE, 50 Hz
• Cold water (CW) connection: 3/4
