Rainwater tank RONDO

water storageabove-groundpolyethylene

Overview
The vertical water collectors Rondo are produced in polyethylene (PE). Their vertical cylindrical design is intended for outdoor installation. Available capacities range from 325 L to 15000 L.

Available sizes and documentation
325 L | Code: 52730 | Dimensions [mm]: ∅ 620 x 1300 | PDF: Rondo_325.pdf | DWG: on request
500 L | Code: 52731 | Dimensions [mm]: ∅ 740 x 1350 | PDF: Rondo_500.pdf | DWG: on request
800 L | Code: 52732 | Dimensions [mm]: ∅ 840 x 1600 | PDF: Rondo_800.pdf | DWG: on request
1000 L | Code: 52733 | Dimensions [mm]: ∅ 950 x 1650 | PDF: Rondo_1000.pdf | DWG: on request
1500 L | Code: 52734 | Dimensions [mm]: ∅ 1100 x 1850 | PDF: Rondo_1500.pdf | DWG: on request
2000 L | Code: 52735 | Dimensions [mm]: ∅ 1200 x 1950 | PDF: Rondo_2000.pdf | DWG: on request
3000 L | Code: 52740 | Dimensions [mm]: ∅ 1860 x 1430 | PDF: Rondo_3000.pdf | DWG: on request
4000 L | Code: 52741 | Dimensions [mm]: ∅ 1860 x 1920 | PDF: Rondo_4000.pdf | DWG: on request
6000 L | Code: 52742 | Dimensions [mm]: ∅ 1860 x 2590 | PDF: Rondo_6000.pdf | DWG: on request
8000 L | Code: 52743 | Dimensions [mm]: ∅ 2460 x 2020 | PDF: Rondo_8000.pdf | DWG: on request
10000 L | Code: 52744 | Dimensions [mm]: ∅ 2460 x 2470 | PDF: Rondo_10000.pdf | DWG: on request
15000 L | Code: 52745 | Dimensions [mm]: ∅ 2460 x 3620 | PDF: Rondo_15000.pdf | DWG: on request

Technical characteristics / specifications

• Material: Polyethylene (PE)
• Shape: vertical, cylindrical
• Intended installation: outdoor
• Capacity range: 325 L, 500 L, 800 L, 1000 L, 1500 L, 2000 L, 3000 L, 4000 L, 6000 L, 8000 L, 10000 L, 15000 L
• Reference codes (selected): 325 L = 52730; 500 L = 52731; 800 L = 52732; 1000 L = 52733; 1500 L = 52734; 2000 L = 52735; 3000 L = 52740; 4000 L = 52741; 6000 L = 52742; 8000 L = 52743; 10000 L = 52744; 15000 L = 52745
• Dimensions: specified per capacity (e.g. 325 L = ∅ 620 x 1300 mm; 15000 L = ∅ 2460 x 3620 mm)
• Technical files: PDF plans named Rondo_.pdf available per size; DWG files available on request
