Hardwood bridge ZEN

COR-TEN® steelarchpedestrian

Product Description
Zen Corten Bridges are compact pedestrian bridges designed for short spans up to approximately 8 m. The structural decking is formed from a single, thick-walled Corten steel plate, providing the load-bearing surface and primary structural element. The bridge features a low fence with a Corten steel railing capped with hardwood and rounded projecting ends. Over time the Corten surface develops a warm brown weathered patina. An optional dot-pattern can be incorporated into the decking to improve slip resistance.

Features

• Single thick-walled Corten steel plate decking (recommended maximum width approx. 200 cm).
• Typical maximum span: approx. 8 m.
• Arched bridge configuration (supplied as an arched unit).
• Low fence combining simple geometry with an oriental-inspired aesthetic; hardwood handrail cap.
• Optional dot-pattern on decking for additional grip.
• Delivered predominantly prefab — on-site installation typically requires only a few days.
• Typical lead time: 12–14 weeks after approval of drawings (subject to client approval process).

Materials info

• Corten Steel — weathering steel with warm red-brown colour and rough texture; recyclable; maintenance: none; time to oxidise: 1–3 years; expected service life: approx. 50 years.
• Powder coating (option) — two-coat polyester finish applicable to steel, aluminium, galvanised steel and Corten; colour: RAL or DB on request; texture: smooth; expected service life approx. 10 years; routine maintenance: annual freshwater cleaning or mild alkaline cleaner if required.

The Bridge Process
Streetlife manages a six-step Bridge Process from concept to delivery: concept, design, approval, fabrication, prefabrication and transport/assembly. Bridges are produced largely in prefab state to reduce on-site works; final delivery time depends on client approvals and project scope.

Technical specifications

• Maximum span per span: approx. 8 m.
• Recommended maximum decking width: up to approx. 200 cm (depending on decking finish).
• Bridge type: arched bridge (standard configuration).
• Main decking and structural plate: thick-walled Corten steel.
• Railing: Corten steel with hardwood cap; projecting ends rounded.
• Optional anti-slip: dot-pattern on decking.
• Customization: primary dimensions and finishes customizable on request.
• Standards: design according to Eurocode plus national annex; fence standard reference NPR-CEN/TR 16949:2016.
• Delivery: prefab delivery; typical lead time 12–14 weeks after drawing approval (subject to client decision times).
