Interior door CRYSTAL

aluminiumsolid woodcrystal

Product overview
The Filomuro Systems collection includes the Filomuro Minima coplanar flush-to-wall door, available with Crystal and Crystal Bi glass variants. The system features an extruded, oxidized aluminium frame designed for surface finishing and anchoring to both traditional masonry and plasterboard. The leaf is 44 mm thick with a solid wood perimeter frame and IPER 4 BOARD perimeter stops in ABS.

Materials and construction

• IPER 4 BOARD perimeter stops in ABS, 0.8 mm
• Paintable primer on frame
• Predisposition for masonry and plasterboard installation
• Internal structure: recycled honeycomb 100 # 37
• Available in full-height version up to 3000 mm
• Option: applied mirror

Opening systems

• Hinged (swing)
• Ratchet opening system
• Internal wall sliding
• Doublé
• Bidirectional

Customization and variants
The Filomuro Minima is configurable with single or double leaves and with Crystal or double Crystal Bi glazing. Surfaces can be finished or painted to match interior design requirements. Standard adjustable anti-sagging tie-rods are provided for heights over 2450 mm to ensure flat alignment.

Technical specifications

• Collection: Filomuro Systems (Minima)
• Model: Minima
• Type: Coplanar flush-to-wall door
• Frame: Extruded and oxidized aluminium
• Anchoring: Suitable for traditional masonry and plasterboard
• Leaf thickness: 44 mm
• Perimeter frame: Solid wood with IPER 4 BOARD perimeter stops in ABS
• Opening systems: hinged, ratchet, internal wall sliding, Doublé, Bidirectional
• Glass options: Crystal glass; Crystal Bi double glass
• Internal structure: recycled honeycomb 100 # 37
• Full-height version: available up to 3000 mm
• Options: double door, applied mirror
• Anti-sagging: standard adjustable tie-rods for heights over 2450 mm
