ENGINE
Tier 4 final (stage III b) Isuzu au-4le2x engine
- 41,2 kw
- 2,2 l hydraulics
Water-cooled, 4-stroke diesel, 4-cylinders in line
High capacity fuel tank: 120 l
Auto-idle and one-touch idle
Idle shutdown system
TRANSMISSION
Two-speed hydrostatic transmission, with variable displacement axial piston motor and automatic travel speed shifting
Mechanical disc brakes in oil bath
Final drive with planetary gear reduction in oil bath
HYDRAULIC SYSTEM
Open-center system, two variable displacement axial piston pumps with regulating system for fast cycles and simultaneous movements + 1 independent gear pump for dozer blade operations
Attachment cushion control
3 operating modes (auto, heavy, speed priority)
UNDERCARRIAGE
450 mm steel tracks
450 mm dozer blade
4-lashing points for easy transport
Step on undercarriage for safe cab access
OPERATOR STATION
ROPS & FOPS Level 1
Safety glass for all windows one-touch lock front window
Windshield wiper & washer
7” full-color LCD monitor display
Rear view camera
Side view camera
Automatic climate control
Fully adjustable Mechanical suspension seat
1 working light on boom
1 working light on cab top
