Swing gate automation S800H ENC

gatewith rechargeable battery

Product overview

• Underground operator with hydraulic technology 24V
• Absolute magnetic encoder (for ENC models) with integrated BUS 2easy (non polarized two wires connection)
• Integrated Positive Stops, possibility to avoid mechanical stops installation. FAAC Patent.

HYbrid Core
By combining FAAC’s hydraulic technology with a 24V DC motor, the S800H ENC becomes a robust, reliable, high-performance operator, perfect for high-frequency use. It also supports battery backup operation in case of power failure.

Absolute magnetic encoder with BUS 2easy

• Anti-crushing safety and obstacle-reversal functions are ensured by the presence of an absolute magnetic encoder with BUS 2easy technology (connectable via just two non-polarised wires).
• In the event of a power outage, the absolute encoder retains the gate leaf position in memory, wherever it stopped.

Performance summary

• Max leaf weight: 800 Kg
• Max single leaf width: 2 - 4 m
• Use frequency: Continuous use

Models / Item codes
Model — Item code
S800H ENC CBAC 100° — 108720
S800H ENC SBW 100° — 108724
S800H ENC CBAC 180° — 108722
S800H ENC SBW 180° — 108725

caractéristiques / spécifications techniques

• Power supply voltage: 220-240V ~ 50/60 Hz
• Electric motor: With brushes 24V DC
• Max power: 60 W
• Max leaf weight: 800 kg
• Max leaf width: 2 - 4 m
• Use frequency: Continuous use
