Attic retractable ladder LTK ENERGY

foldingwoodfor domestic use

Overview
The loft ladder LTK Energy is a wooden, 3-section insulated loft ladder combining comfort, energy efficiency and elegant appearance. It features an insulated sandwich hatch, peripheral seals and anti-slip treads. The product is designed to reduce heat loss when correctly installed and to blend harmoniously with interior design thanks to the white hatch and lacquered ladder.

Key benefits

• Improved thermal performance and energy savings due to insulated hatch and seals
• Safe and comfortable access with anti-slip treads and handrail
• Compact 3-section folding ladder for convenient storage
• Aesthetic finish: white hatch and lacquered ladder complement interiors

Features (detailed)

• Insulated sandwich hatch finished with HDF boards on both sides, filled with Styrofoam
• Hatch thickness: 6.6 cm
• Attic ladder thermal transmittance (U-value): 0.68 W/m²K
• Number of peripheral seals in the box: 2 (peripheral seal improves airtightness)
• Airtightness class: 4 (highest)
• Anti-slip treads flush with ladder stringers for safety and neat finish
• Handrail included (1)
• 3-section ladder construction (folded 3-section)
• Ladder lacquered; hatch white for elegant appearance
• Assistance / unloading mechanism (recommended accessory: LXM-W) for easier operation (recommended)
• Installation bracket set LXK recommended for correct installation and levelling

Applications and advantages
The LTK Energy loft ladder is intended for domestic use where energy efficiency and comfort are required. Its insulated hatch and peripheral seals reduce heat loss, contributing to lower heating/cooling costs. The ladder ensures safe everyday use via anti-slip treads and a reliable handrail, while the lacquered ladder and white hatch provide a refined look that integrates with modern interiors.

Technical specifications

• Denomination: LTK Energy
• Ceiling opening dimensions (W x L/H): 55 x 120 / 280 cm
• Selected (commercial) size: 55x120/280 cm
• Minimum room height: 235 cm
• Maximum room height: 280 cm
• Swing clearance: 164 cm
• Maximum projection with ladder unfolded: 129 cm
• Height of folded ladder: 35 cm
• Box height: 18 cm
• Box material: Pinewood
• Ladder material: Pinewood (lacquered ladder)
• Ladder width: 34 cm
• Ladder construction: Folded 3-section
• Ladder angle: 68.8–70.6°
• Number of steps: 12
• Step thickness: 2 cm
• Step depth: 8 cm
• Step width: 30 cm
• Distance between steps: 25 cm
• Maximum load (capacity): 160 kg
• Product weight: 30.4 kg
• Packaging width: 0.534 m
• Packaging length: 1.184 m
• Packaging height: 0.375 m
• Packaging method: Tied with transportation belts
• Feet: Plastic
• Handrail: 1 (included)
• Counterbalancing mechanism: No
• Hatch type: Insulated sandwich hatch finished with HDF board on both sides, filled with Styrofoam
• Hatch lock type: Lock
• Hatch thickness: 6.6 cm
• Number of peripheral seals in the box: 2
• Attic ladder U-value: 0.68 W/m²K
• Airtightness class: 4 (highest)
• Installation method: Simple assembly (attachable flaps, so-called click). Product supplied completely assembled
• Hatch installation method: Click grip
• Recommended accessories: Installation bracket set LXK; unloading mechanism LXM-W for 3-section wooden ladders; balustrade LXB-P; finishing slat LXL-P; other finishing and installation accessories
