Attic retractable ladder LMP

foldingtelescopicsteel

Product overview
The LMP attic ladder is a folding 3-section access ladder designed for high rooms up to 366 cm. It combines a powder-coated steel ladder with an insulated sandwich hatch to provide safe, thermally efficient access to lofts and attics. The product is supplied assembled for straightforward installation.

Key features

• Peripheral seal
• Anti-slip treads
• Adjustable stile ends to protect flooring and ensure stability
• Telescopic handrail with folding/unfolding mechanism
• Insulated sandwich hatch finished with HDF board on both sides, filled with Styrofoam
• Powder-coated steel ladder (RAL 7022)
• Support and unloading mechanism integrated in the handrail for comfortable operation at height
• Counterbalancing mechanism to ease unfolding and folding

Suitable for high rooms
This model fits interiors with ceiling heights from 300 cm up to 366 cm. Adjustable ladder length and robust 3-section folding construction ensure a proper fit and secure access in rooms with high ceilings.

Comfort of use and assistance systems
The ladder is equipped with a support system that simplifies unfolding and folding when installed at great heights. The unloading mechanism concealed in the handrail reduces effort during operation, while the telescopic handrail provides stable support during ascent and descent.

Materials and appearance
The box is manufactured from pinewood. The ladder structure is steel with a powder-coated finish in RAL 7022. The hatch is a white insulated sandwich panel filled with Styrofoam and finished with HDF boards on both sides.

Installation and accessories
The product is delivered fully assembled. The hatch is intended to be fixed by screws during installation. Recommended installation accessories: installation brackets (LXK), mounting wedges (LXP) and dedicated screw sets (LXF-C / LXF-W). Optional accessories: balustrade LXB-P and attic handrail LXH-A.

Downloads and documents
Available documentation includes EPD and declarations related to performance and formaldehyde emissions, providing certificates and technical statements relevant to the LMP attic ladder.

Technical specifications

• Selected commercial size: 60x144/366 cm
• Ceiling opening dimensions W x L/H: 60x144/366 cm
• Minimum room height: 300 cm
• Maximum room height: 366 cm
• Swing clearance: 196 cm
• Maximum projection with the ladder unfolded: 145 cm
• Height of the folded ladder: 32 cm
• Box height: 18 cm
• Box material: Pinewood
• Ladder material: Steel, powder-coated (RAL 7022)
• Hatch colour: White
• Hatch type: Insulated sandwich hatch finished with HDF board on both sides, filled with Styrofoam
• Hatch lock type: Latch
• Hatch thickness: 3.6 cm
• Ladder width: 38 cm
• Ladder construction: Folded 3-section
• Ladder angle: 68.5 - 70.5°
• Number of steps: 16
• Step thickness: 3.2 cm
• Step depth: 8 cm
• Step width: 34 cm
• Distance between steps: 24 cm
• Maximum load: 200 kg
• Number of seals in the box: 1
• Hatch thermal transmittance (U-value): 1.1 W/m²K
• Hatch thermal insulation thickness: 3 cm
• Airtightness class: npd
• Feet: Plastic
• Handrail: Telescopic railing with folding and unfolding mechanism
• Counterbalancing mechanism: Yes
• Installation method: Product completely assembled
• Hatch installation method: Screwed
• Product weight: 47.3 kg
• Packaging width: 0.582 m
• Packaging length: 1.432 m
• Packaging height: 0.265 m
