Electric scooter charging station 2663-010500-0401114_V.1603

for electric bikegalvanised steelpainted steel

Presentation
The LOCKEEL® e-bike charging station is designed for secure outdoor storage and simultaneous charging of batteries for e-bikes, pedelecs, electric scooters, tools and other technical devices. It features four spacious compartments, each fitted with two Type F sockets (IP55, 230 V, 16 A) with surge protection for safe charging in adverse weather.

Construction and protection
The cabinet is made from moisture- and weather-resistant galvanized steel sheet with UV-stable oven-baked enamel finish. Double-walled doors provide dust- and water-resistant storage. Doors close flush and use rubber bumpers to reduce noise.

Charging and compartments
Each of the four compartments includes two IP55 sockets (230 V, 16 A) with integrated surge protection. A lockable service compartment is provided at the base for electrical equipment and maintenance access.

Base and installation
The rust- and weather-resistant base includes leveling feet for a stable mounting. The base is pre-drilled to allow secure anchoring to a concrete foundation.

Key features

• Robust construction (body sheet thickness: 1.0 mm; doors: 1.5 mm)
• Suitable for e-bikes and electric scooters
• Weatherproof storage and charging
• Designed for outdoor use

Options and delivery
The charging station is available in several colour finishes and can be supplied with different locking systems on request. The service compartment is fitted with a cylinder lock as standard.

Technical characteristics / Specifications

• Number of doors: 4
• Compartment depth: 60 cm
• Tray height: 36.9 cm
• Tray width: 40 cm
• Locking system: Cylinder lock, 2 keys
• Charging socket: Type F plug
• Material: Galvanized steel sheet
• Sheet thickness body: 1.0 mm
• Sheet thickness door: 1.5 mm
• Height: 215 cm
• Depth: 63 cm
• Width: 46 cm
• Weight: 120 kg
