Water pump GHV HVX+

with electric motormetal

Overview
GHV HVX+ Smart Controller listed in the CAD centre. This entry centralises downloadable CAD resources for multiple GHV series configurations (GHV2, GHV3, GHV4) and details product configuration codes with the number of service pumps and the corresponding service pump hydraulics.

Document types available (per product entry)

• 2D drawings: DXF (provided as .ZIP)
• 3D models: STP (provided as .ZIP)
• 2D preview images: PNG
• 3D previews: 3D viewer files (3DM) or gzipped HTML previews

Models and key additional info (excerpt)
The listing covers GHV2 (20 = 2 service pumps), GHV3 (30 = 3 service pumps) and GHV4 (40 = 4 service pumps). Common service pump hydraulics include 33SV, 46SV, 66SV, 92SV and 125SV. For each product entry downloadable files (2D .dxf and 3D .stp) and 2D/3D previews are provided.

Examples of product codes (excerpt): GHV2/125SV4G/AA/A1A — 20 = 2 service pumps — 125SV; GHV3/125SV6G/AA/A2A — 30 = 3 service pumps — 125SV; GHV4/46SV8G/AA/A2A — 40 = 4 service pumps — 46SV.

Notes
Each table row typically provides: product configuration code, number of service pumps and service pump hydraulics, downloadable CAD documents in 2D (DXF) and 3D (STP) formats (packaged as ZIPs), and 2D/3D preview options. No pricing or EAN information is displayed on the page.
