Vertical evaporator ice cube maker NEO® 65/80

undercounterfor commercial kitchenfull cube

Overview
Compact undercounter ice machine combining an ice maker and storage bin in one stainless-steel unit, intended for small-volume commercial applications. AlphaSan® antimicrobial protection and front air intake/exhaust reduce maintenance requirements and allow flexible installation.

Features

• Sanitation & Maintenance
  • AlphaSan® antimicrobial protection integrated into key internal components to support extended cleaning intervals.
  • Patented Cleaning and Sanitizing System for efficient routine maintenance.
  • Easy-access air filter designed to operate longer in greasy or dusty environments.
• Design & Durability
  • Stainless-steel cabinet with coordinated interior surfaces for hygienic operation.
  • Slide-up door providing unobstructed access for loading and cleaning.
  • Flat, right-angle plug to simplify installation in confined spaces.
• Performance & Placement
  • Uses R134A refrigerant.
  • Front air intake and exhaust enable installation under counters or as a freestanding unit.
  • Compact footprint suitable for space-constrained environments.
• Functionality & Innovation
  • Integrated ice maker and bin tailored for small-volume applications.
  • Proprietary vertical evaporator technology engineered in Manitowoc, WI for consistent ice production.

Technical Specifications (per model)
UDE-0065A
Power Output: N/A
Power Input Type: Electric
Primary Power Input: 115-120 V x 60 Hz x 1 PH
Certifications: AutoQuotes, CE, CUL, NSF

UDE-0080A
Power Output: N/A
Power Input Type: Electric
Primary Power Input: 115-120 V x 60 Hz x 1 PH
Certifications: AutoQuotes, CE, CUL, NSF

General specifications

• Model: NEO® 65/80
• Refrigerant: R134A
• Integrated ice maker and storage bin (undercounter configuration)
• Sanitation: AlphaSan® antimicrobial protection in key internal components
• Cleaning: Patented Cleaning and Sanitizing System
• Airflow: Front air intake and exhaust for flexible placement
• Cabinet: Stainless-steel construction
• Door: Slide-up door for unobstructed access
• Electrical: Primary power input 115-120 V, 60 Hz, single phase
• Plug: Flat, right-angle plug for tight-space installation
• Technology: Proprietary vertical evaporator
• Certifications: AutoQuotes, CE, CUL, NSF
