Undercounter ice cube maker NEO® Series

for commercial kitchenfull cubeair cooling

Overview
NEO undercounter ice machines UP140 and UP190 deliver ice at the point of use with integrated water filtration and next-generation cooling. Designed for commercial environments where footprint, hygiene and operating efficiency matter.

Key features

• Integrated Water Filtration
  • Cleaner, clearer ice for improved beverage quality.
  • Filtration supports consistent peak performance of the ice machine.
  • Reduced maintenance frequency and easier sanitation.
• Sustainability
  • R290 refrigerant for lower environmental impact.
  • Improved energy and water efficiency to reduce operating costs.
  • ENERGY STAR® qualification available on selected models.
• Convenience
  • Foodzone layout for simplified access and maintenance.
  • Intuitive status and service indicators for quick diagnostics.
  • Removable bins and filters for straightforward cleaning.
• Commercial Warranty
  • 3 years parts and labor for ice maker components.
  • 5 years parts and labor for evaporator components.
  • Compressor: 5 years parts, 3 years labor.

Accessories

• 0.5 Micron Replacement Water Filter Cartridge — Kit Number K00531
• 5 Micron Replacement Water Filter Cartridge — Kit Number K00530
• LuminIce® II Virus and Bacteria Inhibitor — controls viruses, bacteria, mold and yeast within the food zone to extend time between cleanings.

Documents and media available on product page

• Brochure (NEO Brochure)
• Diagrams (e.g. UP0140A and UP0190A diagrams)
• Owner instruction manuals and service bulletins (NEO UP Ice Machines IOM, NEO UP - Air & Water-cooled IOM, MII_SB_0080 and MII_SB_0084)
• Specification sheets and technicians handbook (NEO 140/190 series spec sheets, NEO Series (all models) Technicians Handbook)

Specifications / Technical data

• Common data (general for NEO UP140/UP190 series)
  • Category: Undercounter Ice Machines
  • Unit type: Electric
  • Primary power input (typical): 115-120 V x 60 Hz x 1 PH
  • Dimensions (W x D x H, typical): 26" x 28.5" x 32.5" — 66 cm x 72.4 cm x 82.6 cm
  • Certifications: AHRI, AutoQuotes, CE, ENERGY STAR, NSF, UL (as shown on spec tables)
• URP-140A
  • W x D x H: 26" x 28.5" x 32.5" (66 cm x 72.4 cm x 82.6 cm)
  • Weight: 153 lb / 69.4 kg
  • Power Input Type: Electric
  • Primary Power Input: 115-120 V x 60 Hz x 1 PH
  • Energy Use: 7.25 kWh/100lbs ice
• UDP-140A
  • W x D x H: 26" x 28.5" x 32.5" (66 cm x 72.4 cm x 82.6 cm)
  • Weight: 150 lb / 68 kg
  • Power Input Type: Electric
  • Primary Power Input: 115-120 V x 60 Hz x 1 PH
  • Energy Use: 7.25 kWh/100lbs ice
• UYP-140A
  • W x D x H: 26" x 28.5" x 32.5" (66 cm x 72.4 cm x 82.6 cm)
  • Weight: 153 lb / 69.4 kg
  • Power Input Type: Electric
  • Primary Power Input: 115-120 V x 60 Hz x 1 PH
  • Energy Use: 7.25 kWh/100lbs ice
• UDP-190A
  • W x D x H: 26" x 28.5" x 32.5" (66 cm x 72.4 cm x 82.6 cm)
  • Weight: 153 lb / 69.4 kg
  • Power Input Type: Electric
  • Primary Power Input: 115-120 V x 60 Hz x 1 PH
  • Energy Use: 5.83 kWh/100lbs ice
• UYP-190A
  • W x D x H: 26" x 28.5" x 32.5" (66 cm x 72.4 cm x 82.6 cm)
  • Weight: 153 lb / 69.4 kg
  • Power Input Type: Electric
  • Primary Power Input: 115-120 V x 60 Hz x 1 PH
  • Energy Use: 5.83 kWh/100lbs ice
