Hinged solar shading Motion 10700

aluminumfor facadelouvered

The Vertical Hinged shading system is made up of a sash hinged at the top moving upwards. This creates a horizontal outward projection to the building leading to a shade being created while allowing natural light to enter the building. This kind of shading system is mostly suitable for windows. The sash movement is vertical and can only be operated electrically. The max sash height is limited to 1.5 meters in height and 4 meters in width. In its standard installation configuration, it is mounted within the building frame. Optionally it can also be fixed on the outside thus creating seamless integration with the building cladding. In its typical configurations the system can accommodate cladding options like natural wood, GRP, Glass, Fiber Cement, Ceramic, Perforated Metal Sheets, Aluminum blades and ACP. The system can be installed directly on the building opening without the need for any special provisions. The only necessary consideration is the wiring arrangement. In total the system requires a depth of 150mm to accommodate the motors as well as the sash internal rotation. This electric hinged shading system can be centrally controlled by the Building Management System or individually via a wall mounted switch / remote control in single or group mode.
