Polypropylene raised floor pedestal UPTEC SUPA4FX

rubberacousticoutdoor

The Uptec SUPA4FX is an accessory for raised-floor pavers designed for use with Uptec pedestal systems. It has a molded rubber head and polypropylene tabs that enable noise reduction and anti-slip behaviour while allowing configurable joint spacing according to installation needs.

Presentation and composition

• Two-component construction: polypropylene tabs and a rubber head for noise reduction and anti-slip properties.
• Removable tabs: tabs can be removed using the SUPAK key to adapt to different floor configurations.
• Intended joint size: designed to create a 4 mm joint (product page also references 2 mm tabs in other variants).

Usage and compatibility

• Designed for use with Uptec pedestals SUPALFX and SUPASFX.
• Compatible with SUPAL and SUPAS pedestal ranges and with the SUPAANG240 aluminium joist.
• Accessory for laying pavers on raised/floating floors; must be combined with the cited Uptec pedestal systems.

Technical documents and visuals

• Technical datasheets and sectional visuals (front and lateral views, GIFs) are available on the product page.

Specifications

• Model / reference: SUPA4FX
• S (joint size): 4 mm (product page contains references to 2 mm tabs as well)
• Material: rubber head + polypropylene tabs (co-moulded)
• Tabs: removable with SUPAK key
• Finish: Recycled (product finishing option)
• Primary functions: joint spacing for pavers on raised floors, noise reduction, anti-slip
