Pendant lamp TUBO 60

aluminumcontemporarycorded

Quickinfo
3000 K, 4000 K
CRI ≥80; CRI ≥90 (options)
3 SDCM (initial MacAdam)
up to 3,280 lm/m
up to 142 lm/W
L90 / 50,000 h
Covers: Clear, Opal; optional linear prismatic optic
DALI-2
IP20

Description
Supporting profile in extruded aluminium; aluminium end caps; surface finish: raw aluminium or powder coated. Suspended luminaire with cable suspension and tool-free height adjustment; feeder cable included. Light control via a lens system designed for homogeneous linear illumination. Optional cylindrical opal cover or clear cylindrical cover with linear prismatic optic. LEDs available with selectable colour rendering (CRI ≥80 or CRI ≥90).

Features

• Supporting profile: extruded aluminium
• End caps: aluminium
• Surface: raw aluminium or powder coated
• Mounting: cable suspension with tool-free height adjustment (suspended luminaire)
• Includes feeder cable
• Optical control via high-quality lens system for uniform illumination
• Optional covers: cylindrical opal cover or clear cylindrical cover with linear prismatic optic
• LED: energy-efficient with selectable CRI options (≥80 / ≥90)
• Dimming interface: DALI-2
• Protection rating: IP20

Applications & System
Integrated driver; suitable as a system solution compatible with profile/system luminaires. Provides uniform linear illumination for suspended ceiling and general industrial or commercial installations.

Technical specifications

• Model family: TUBO 60 (suspended)
• Colour temperatures: 3000 K, 4000 K
• Colour rendering: CRI ≥80; CRI ≥90 options
• Tolerances: 3 SDCM (initial MacAdam)
• Luminous flux: up to 3,280 lm per metre
• System efficacy: up to 142 lm/W (depending on configuration)
• Lumen maintenance: L90 at 50,000 h
• Covers: Clear, Opal; optional linear prismatic optic (clear cylindrical cover)
• Dimming interface: DALI-2
• IP rating: IP20
• Materials: extruded aluminium profile, aluminium end caps
• Mounting: cable suspension; height adjustment without tools; includes feeder cable
• Variants: multiple lengths and output options (see product codes / datasheets)
