Original design ceiling light PUKEBERG ORIGINAL

circularopalglass

Finish
Chromed metal parts with an opal glass shade.

LED info
System power: 12W (integrated LED) with luminous flux 1500 lm. Correlated Colour Temperature (CCT): 3000K. SDCM 3. CRI >80. E27 lamp option available (max 20W).

Installation
Suspended installation through a fixed tube. Standard tube length 700 mm; other lengths available on request.

Connection
Ceiling cup with snap-in terminal block 5×4 mm2. Supply and installation connections per project requirements.

Classification
Ingress protection: IP20. Suitable for indoor architectural and design applications.

Design
Shade produced from original glass moulds from Pukeberg Glassworks, preserving historic glass forming details.

Standard colours
Standard: opal glass with chromed metal. Alternative finishes and colours available on request.

Product specification
Pukeberg Original fixtures are manufactured in original Pukeberg glass moulds.
W | H/MM | KG | ART
E27 / max 20W | 470 | 5.8 | 5083182
E27 / max 20W | 450 | 5.8 | 5082182
LED 1500 lm / 12W | 450 | 5.8 | 5285182
LED 1500 lm / 12W | 450 | 5.8 | 5285182HFF
LED 1500 lm / 12W | 470 | 5.8 | 5286-1-82
LED 1500 lm / 12W | 470 | 5.8 | 5286-1-82HFF

Technical specifications

• Finish: Chromed metal parts; opal glass shade.
• Light source options: E27 max 20W or integrated LED 1500 lm / 12W.
• LED performance: 1500 lm, 12W, CCT 3000K, SDCM 3, CRI >80.
• Installation: Suspended via fixed tube; standard tube 700 mm (other lengths on request).
• Connection: Snap-in terminal block 5×4 mm2 in ceiling cup.
• Ingress protection: IP20 (indoor use).
• Weight: ≈5.8 kg (per item entry).
• Article codes: 5083182, 5082182, 5285182, 5285182HFF, 5286-1-82, 5286-1-82HFF.
• Dimmability: Models with suffix HFF are dimmable via DALI and SwitchDim.
• Design origin: Made in original glass moulds from Pukeberg Glassworks.
