Smoking cabin with filter 3SR65

metalwith built-in lightingwith built-in ashtray

Overview
The 3SR65 smoking unit is a freestanding, modular smoking cabin designed to capture and filter tobacco smoke, gases and odours. It integrates a staged filtration and ventilation system, is constructed from selected materials for operational and fire safety, and can be supplied with or without integrated ashtrays depending on site requirements.

Product highlights

• Filtration and ventilation system capturing smoke at source to prevent emissions outside the cabin
• Freestanding modular construction enabling easy reduction or expansion of cabin size
• Automatic door with wheelchair-accessible opening
• LED lighting with automatic on/off based on presence detection
• Certified fireproof aluminium ashtray options (single or double)
• High-efficiency fan providing strong airflow with reduced operating cost
• Sensor activation for power-saving control of lighting and ventilation
• Optional customisation: LED screen, various integrated ashtray sizes, bespoke colours

Technology and operation
The system captures smoke at source and routes it through staged filtration so particles, gases and odour are removed before air is exhausted. Filters are individually tested and require regular maintenance to maintain performance. The cabin is leak-tested to contain smoke and protect surrounding areas from passive smoking and nuisance odours.

Technical specifications

• Model: 3SR65
• Dimensions (W x D x H) – Weight incl. filters: 820 x 920 x 2200 mm – ≅ 200 kg
• Main materials: Frame: Steel SPCC 1.5 mm; Front panel: Medium Density Fiberboard (MDF)
• Available finishes: Powder coated steel RAL 9005 (black) or RAL 9006 (grey); front veneers: Mahogany, Maple, Walnut, White, Black; other colours optional
• Leak tested: Yes
• Recommended capacity / area: Up to 4 persons / up to 20 m²
• Adjustability: Variable airflow speeds for standby and operating modes
• Certifications: ISO 9001:2015, ISO 14001:2015; fireproof ashtray tested by DBI; non-smoker protection tested by I.F.I. Germany; CE marking
