Tempered glass panel OPALIT® EVOLUTION

translucentcoloredenameled

Presentation
OPALIT EVOLUTION is a translucent enamelled toughened glass. Its clear or coloured appearance is achieved by depositing, on one face, a layer of translucent enamel fired at high temperature and fully integrated into the glass surface. It combines a contemporary frosted look with the performance of enamelled toughened glass for interior and exterior use.

Applications

• Partitions, shower panels, framed or frameless doors
• Furniture: tables, office furniture, shelves, cabinet doors, etc.
• Glazed façades, translucent spandrels
• Street furniture, signage

Benefits

• Privacy and luminous colours: transmits light while protecting from direct view; frosted appearance available in several shades for façades and interiors.
• Exceptional durability and safety: retains all the properties of enamelled toughened glass; colour permanence ensured by the manufacturing process.
• Environmental performance: use of lead- and cadmium-free enamels to facilitate recycling.

Selection criteria
OPALIT EVOLUTION is a diffusing product. Colour intensity may vary with viewing angle and lighting. It is recommended to verify the intended aesthetic in situ and to produce a full-scale prototype placed in the final environment.

Range
Available in three shades: natural, blue and green. The natural shade can be manufactured on DIAMANT® extra-clear glass for specific aesthetic requirements.

Recommendations
Colours vary slightly with glass thickness. For uniform colour, use a single glass thickness per project. Slight variations may occur between production batches: prefer using the same production run for a given project.

Care instructions
To preserve its aesthetic qualities, OPALIT EVOLUTION should be cleaned regularly with neutral agents free of aggressive abrasive substances.

Characteristics / technical specifications

• Type: translucent enamelled, toughened glass
• Process: enamel deposited on one face, fired at high temperature and integrated into the surface
• Compliance: toughened glass compliant with EN 12150
• Visual quality control: assessment by transparency at 2 m against a uniformly illuminated background
• Permitted defects: slight coating omissions; small dark spots Ø max 1.5 mm; small white spots max length 2.5 mm
• Admissible concentration: max 3 defects in a 0.5 x 0.5 m square and 5 defects per volume
• Lead- and cadmium-free enamels (better recyclability)
• Available shades: natural, blue, green (possibility to manufacture on DIAMANT® extra-clear glass for natural)
• Recommended uses: interior fit-outs, furniture, showers, doors, façades, translucent spandrels, street furniture and signage
