Solar glass panel PLANICLEAR®

laminateddouble-glazedtriple-glazed

Description
PLANICLEAR® is the new clear float glass from Saint‑Gobain. Designed to meet current market needs, it replaces PLANILUX. Less tinted and more transparent, it improves aesthetic appearance and reduces architectural constraints, giving designers greater freedom.

Applications
PLANICLEAR® is a clear float glass with enhanced optical and aesthetic properties. Typical interior applications include:

• interior fit-out and decoration: doors, partitions, shower screens
• furniture: tabletops, shelves

Exterior uses follow standard glass applications:

• shopfronts and storefront glazing
• double and triple glazing for façades
• street furniture
• etc.

PLANICLEAR® is also a common base glass for processing:

• enameled or screen-printed glass
• laminated and tempered glass
• coated glass
• etc.

Advantages
GREATER TRANSPARENCY
With higher light transmission than traditional clear glass, PLANICLEAR® helps create bright interiors. Its clarity is particularly noticeable in thick monolithic or laminated applications: partitions, interior doors, shower enclosures, shop windows, etc.
SLIGHTLY BLUISH TINT
Its very light bluish tint highlights decorative elements such as tabletops, shelves and counters.
BETTER COLOUR RENDERING
High transparency ensures faithful colour rendering, ideal for shop windows (retail, museums, furniture, etc.). Because it does not alter colours, PLANICLEAR® is particularly suitable for lacquering, enamelling and white or pastel colour concepts.

Technical characteristics (table)
PLANICLEAR®
Thickness (mm): 2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 15 | 19
Visible light transmittance TL (%): 91 | 91 | 91 | 90 | 90 | 89 | 89 | 88 | 87 | 86
Energy transmittance TE (%): 89 | 88 | 87 | 86 | 85 | 83 | 81 | 79 | 77 | 73
AE (%): 3 | 4 | 5 | 6 | 7 | 10 | 12 | 14 | 16 | 20
Solar factor g (%): 0.90 | 0.89 | 0.88 | 0.87 | 0.87 | 0.85 | 0.84 | 0.82 | 0.80 | 0.78

Technical specifications

• Type: clear float glass
• Commercial name: PLANICLEAR®
• Replaces: PLANILUX
• Available thicknesses (mm): 2, 3, 4, 5, 6, 8, 10, 12, 15, 19
• Visible light transmittance TL (%) by thickness: 2 mm=91, 3 mm=91, 4 mm=91, 5 mm=90, 6 mm=90, 8 mm=89, 10 mm=89, 12 mm=88, 15 mm=87, 19 mm=86
• Energy transmittance TE (%) by thickness: 2 mm=89, 3 mm=88, 4 mm=87, 5 mm=86, 6 mm=85, 8 mm=83, 10 mm=81, 12 mm=79, 15 mm=77, 19 mm=73
• AE (%) by thickness: 2 mm=3, 3 mm=4, 4 mm=5, 5 mm=6, 6 mm=7, 8 mm=10, 10 mm=12, 12 mm=14, 15 mm=16, 19 mm=20
• Solar factor g (%) by thickness: 2 mm=0.90, 3 mm=0.89, 4 mm=0.88, 5 mm=0.87, 6 mm=0.87, 8 mm=0.85, 10 mm=0.84, 12 mm=0.82, 15 mm=0.80, 19 mm=0.78
• Advantages: improved transparency, slight bluish tint, faithful colour rendering
• Typical uses: interior fit-out, façades, shop windows, base glass for processing (lacquering, enamelling, tempering, laminating, coating)
