Compact model for reduced space areas.
2 speeds.
Fully stainless steel jacket.
Stainless steel central rack feed system.
Process cycles are divided by rubber curtains.
Automatic cycle start.
Economy
Energy saving rinse supply switch.
Pressure controller in the rinse section to limit consumption.
Programmed automatic stops if there is no loading.
Stop and freezing of timer when the limit switch actuates.
Cleaning and maintenance
Wide pivoting door allowing access for cleaning or inspection purpose.
Detachable arms and dispersers for easier cleaning.
Sloped removable stainless steel filters.
Easy boiler emptying by loosening a hose.
Failures are easily detected thanks to the warning lights.
Easy to repair without moving the machine.
Specifications Sheet
Production
Production baskets/hour: 100
Production plates/hour: 1800
Wash
Temperature: 55 ºC - 65 ºC
Wash tank capacity: 80 l
Pump: 2 Hp / 1500 W
Wash heating element: 7500 W
Rinse
Temperature: 80 ºC - 90 ºC
Water consumption: 270 l/h
Rinse heating element: 18000 W
Boiler capacity: 20 l
Drag
Drag motor power: 0.25 Hp / 180 W
Loading
Central module total power : 27135 W
External dimensions (WxDxH)
Width: 1180 mm
Depth: 829 mm
Height: 1430 mm
Net weight:200 Kg
Water Intake: 3/4 "
Drain diameter: 1 1/2 "
Noise level (1m.): 71 dB(A)
Optional accessories
Drying unit: TS-600
Extraction systems: CA/EV/CV
Tables
