Light switch T02

touchrecesseddouble

Description Easily modernise your electrical installation with this 2-circuit one-way touch switch. Thanks to precise touch control and discreet LED backlighting, it lets you control two lighting points or two lighting groups independently while adding a contemporary look to interiors. Compatible with standard electrical wiring, this mechanism is particularly suited to renovation projects because it operates without a neutral wire at the switch. Pair it with a tempered glass faceplate (sold separately) for a durable finish: the colour is embedded behind the glass for long-term resistance.

Product highlights

• Precise touch control for intuitive daily use
• Quick retrofit installation on existing wiring
• Operates without neutral wire at the switch, ideal for renovations
• Discrete LED backlight for easy location in the dark
• Premium finish when combined with tempered glass faceplate (sold separately)
• Wide compatibility with LED and halogen loads

Installation & compatibility

• Fits round or square back boxes ≥ 40 mm
• Can be mounted horizontally or vertically
• Designed for standard existing electrical installations
• Neutral wire required only at the light fitting, not at the switch
• Compatible with LED lighting
• Compatible with halogen lighting

Pair it with A gloss or matt tempered glass faceplate and a matching metal mounting frame (sold separately).

What's in the box

• One-way touch switch mechanism, 2 buttons
• Installation guide
• Glass faceplate and metal mounting frame sold separately

Technical specifications

• Manufacturer: Livolo
• Reference: T02
• Dimensions: 45 x 45 x 35 mm
• Type: One-way touch switch
• Number of circuits: 2 lighting circuits
• Minimum load: 5 W
• Operating temperature: -10°C to +40°C
• Connection: Screw terminal
• Cable cross-section: 1.5 to 2.5 mm²
• Certification: CE & RoHS
• Maximum power: 2000 W
• Permissible humidity: up to 95%
• Stripping length: 6 mm
• Category: Switch
• Function: One-way
• Number of buttons: 2
