Light switch PP-T01S-A12B

touchelectronicrecessed

Description Modernize your electrical installation with this ready-to-install two-way touch switch supplied with the touch mechanism, metal mounting bracket and gloss white tempered glass faceplate. Designed to control a lighting circuit from two switching points, it is suitable for hallways, staircases, bedrooms or large rooms. Its touch control provides smooth, intuitive operation and a discrete LED backlight makes the switch easy to locate in the dark. Compatible with standard electrical installations, the switch does not require a neutral wire at the switch location, simplifying installation in renovation and new construction. The faceplate is made of tempered glass with the colour applied behind the glass to preserve finish and resistance to scratches and impacts.

Product highlights

• Ready-to-install product
• Supplied complete
• Control of a light from two points (two-way function)
• Precise, intuitive touch control
• Tempered glass faceplate
• Metal support included
• Discreet LED backlighting
• Compatible with LED and halogen lighting
• Quick installation on existing wiring
• Modern, elegant design

Pack contents

• 1 x touch switch - two-way, 1 button (ref. T01S)
• 1 x glass faceplate - 1 button, white, gloss (ref. A-C1-11B)

Installation & compatibility

• Compatible with round or square back boxes ≥ 40 mm
• Horizontal or vertical mounting
• For use on a standard electrical installation
• Neutral wire not required at the switch (only at the light fitting)
• Compatible light sources (LED and halogen lighting)

What’s in the box

• 1 two-way 1-button touch switch mechanism
• 1 glass faceplate - 1 button, white, gloss
• 1 metal mounting bracket
• 1 installation guide

Technical specifications

• Manufacturer: Livolo
• Reference: PP-T01S-A12B
• Type: Touch faceplate
• Number of circuits: 1 lighting circuit
• Minimum load: 5 W
• Maximum power: 2000 W
• Material: Tempered glass
• Certification: CE & RoHS
• Function: Ready-to-install two-way switch (Two-way)
• Number of buttons: 1
