Light switch PP-T01-A11B

touchrecessedtempered glass facing

Short description
Choose a ready-to-install solution with this one-way 1-gang touch switch supplied with its mechanism, metal mounting frame and gloss white tempered glass faceplate.

Overview
Modernise electrical installations with this ready-to-fit 1-gang one-way touch switch. The unit includes the touch mechanism, metal frame and a gloss white tempered glass faceplate. Touch control provides intuitive operation and a discreet LED backlight helps locate the switch in low light. Compatible with standard installations and suitable for renovation or new build projects, the module does not require a neutral wire at the switch, simplifying retrofit integration. The faceplate colour is applied behind the glass for improved scratch and wear resistance.

Product highlights

• Ready-to-install solution supplied complete
• One-way (1-circuit) 1-gang touch mechanism
• Tempered glass faceplate, gloss white
• Metal mounting frame included
• Discreet LED backlighting for night identification
• Quick installation on existing wiring (no neutral required at switch)
• Compatible with LED and halogen light sources
• Reference: PP-T01-A11B (manufacturer: Livolo)

Pack contents

• 1 x touch switch – one-way 1 button (ref. T01)
• 1 x glass faceplate – 1 button, white, gloss (ref. A-C1-11B)

Installation & compatibility

• Compatible with round or square back boxes ≥ 40 mm
• Horizontal or vertical mounting possible
• For use on standard electrical installations
• Neutral wire not required at the switch (neutral remains at the luminaire)
• Compatible light sources: LED and halogen lighting

What's in the box

• 1 touch switch mechanism – 1-button one-way
• 1 glass faceplate – 1 button, white, gloss
• 1 metal mounting bracket
• 1 installation guide

Caractéristiques / spécifications techniques

• Manufacturer: Livolo
• Reference: PP-T01-A11B
• Type: Touch faceplate
• Number of circuits: 1 (1 lighting circuit)
• Minimum load: 5 W
• Maximum power: 2000 W
• Certification: CE & RoHS
• Material: Tempered glass
• Categories: Ready-to-fit products; Switch
• Function: One-way ready-to-fit switch
• Number of buttons: 1
