Light switch PP-T01-A13B

touchrecessedmetal

Short description
Choose a ready-to-install solution with this one-way touch switch, supplied with its touch mechanism, metal frame and gloss white tempered glass faceplate.

Product highlights

• Ready-to-install product, ideal for retrofit and new installations
• Supplied complete with mechanism, frame and faceplate
• One-way (single-circuit) 1-button touch mechanism
• Tempered glass faceplate with gloss white finish
• Sturdy metal mounting frame included
• Discreet LED backlighting for status indication
• Quick installation on existing wiring
• Compatible with LED and halogen light sources
• Contemporary premium design suitable for commercial and residential projects

Pack contents

• 1 x touch switch - one-way 1 button (ref. T01)
• 1 x glass faceplate - 1 button, white, gloss (ref. A-C1-11B)

Installation & compatibility

• Compatible with round or square back boxes ≥ 40 mm
• Can be mounted horizontally or vertically
• Designed for standard electrical installations
• Neutral wire not required at the switch (neutral only at the light fitting)
• Compatible light sources: LED and halogen

What's in the box

• 1 touch switch mechanism - 1-button one-way
• 1 glass faceplate - 1 button, white, gloss
• 1 metal mounting bracket
• 1 installation guide

Technical specifications

• Manufacturer: Livolo
• Reference: PP-T01-A13B
• Type: Touch faceplate
• Function: One-way ready-to-fit switch
• Number of circuits: 1 lighting circuit
• Number of buttons: 1
• Minimum load: 5 W
• Maximum power: 2000 W
• Material: Tempered glass
• Certification: CE & RoHS
• Categories: Ready-to-fit products; Switch
• Net weight: 0.17 kg
