Blind switch TW02

for roller shutterstouchrecessed

Description Easily control motorised roller shutters and motorised blinds with the Livolo TW02 touch switch mechanism. Designed to operate the full up/down movement of a single tubular motor, the mechanism features intuitive touch control and discreet LED backlighting for simple daily use and easy nighttime location. A single press triggers automatic full travel. The device is compatible with standard electrical installations and requires a neutral wire. When combined with a tempered glass faceplate (sold separately) and a metal mounting frame, it provides a clean, durable finish suitable for commercial and residential projects.

Product highlights

• Up/down control for motorised roller shutters and blinds
• Intuitive touch operation with one‑press automatic travel
• Discreet LED backlight for easy identification in low light
• Fits standard electrical wiring; neutral required
• Compatible with tubular motors and motorised garage doors
• Can be paired with tempered glass faceplates (sold separately)

Installation & compatibility

• Fits round or square back boxes ≥ 40 mm
• Horizontal or vertical mounting
• For standard 220–240 V AC electrical installations
• Neutral wire required for operation
• Compatible equipment: electric roller shutters, motorised blinds, motorised garage doors, tubular motors

Pair it with Tempered glass faceplate (gloss or matt) and metal mounting frame, sold separately.

What's in the box

• Roller shutter touch switch mechanism (Livolo TW02)
• Installation guide
• Glass faceplate and metal mounting frame sold separately

Technical specifications

• Manufacturer: Livolo
• Reference: TW02
• Dimensions: 45 x 45 x 35 mm
• Type: Roller shutter control
• Warranty: 2 years
• Number of circuits: 1 motor (up/down)
• Supply voltage: 220–240 V AC – 50/60 Hz
• Maximum current: 3 A
• Minimum load: 1 W
• Operating temperature: -10 °C to +40 °C
• Connection: Screw terminal
• Cable cross-section: 1.5 to 2.5 mm²
• Certification: CE & RoHS
• Maximum power: 1000 W
• Permissible humidity: Up to 95 %
• Stripping length: 6 mm
• Categories: Switch
• Function: Roller shutter control
• Weight: 0.064 kg
