Light switch PP-T01-A14B

touchrecessedtempered glass facing

Short description
Ready-to-install one-way touch switch supplied with mechanism, metal mounting frame and white gloss tempered glass faceplate. Designed for simple integration into standard electrical installations and compatible with LED and halogen light sources.

Overview
This complete one-way touch switch is delivered ready for installation: touch mechanism, metal frame and gloss white tempered glass faceplate are included. The capacitive touch control ensures intuitive operation while the discreet LED backlight improves visibility in low light. No neutral wire is required at the switch, facilitating retrofit into most existing installations. The colour is applied behind the glass to resist scratches and discoloration, offering a durable, clean finish suitable for modern electrical fittings.

Product highlights

• Ready-to-install product
• Supplied complete (mechanism, frame, faceplate)
• One-way 1-circuit touch mechanism
• Gloss white tempered glass faceplate
• Metal mounting frame included
• Discreet LED backlighting
• Quick integration on existing wiring (no neutral at switch)
• Compatible with LED and halogen lighting
• Slim, low-profile design for professional installations

Pack contents

• 1 x touch switch - one-way 1 button (ref. T01)
• 1 x glass faceplate - 1 button, white, gloss (ref. A-C1-11B)

Installation & compatibility

• Compatible with round or square back boxes ≥ 40 mm
• Horizontal or vertical mounting
• For standard electrical installations
• Neutral wire not required at the switch (only at the light fitting)
• Compatible light sources: LED and halogen

What’s in the box

• 1 touch switch mechanism - 1-button one-way
• 1 glass faceplate - 1 button, white, gloss
• 1 metal mounting bracket
• 1 installation guide

Caractéristiques / spécifications techniques

• Manufacturer: Livolo
• Reference: PP-T01-A14B
• Type: Touch faceplate
• Number of circuits: 1 (1 lighting circuit)
• Minimum load: 5 W
• Maximum power: 2000 W
• Certification: CE & RoHS
• Material: Tempered glass
• Categories: Ready-to-fit products Switch
• Function: One-way Ready-to-fit one-way switch
• Number of buttons: 1
