Double-handle washbasin mixer tap ALR09

wall-mountedmechanicalstainless steel

Details
Deck-mounted mixer tap with double-action control and a wall‑swivel spout, reach L max 170 mm.

Features

• Aerator flow: 5 l/min (1.3 gpm) — water saving
• Auxiliary bracket for plasterboard / gypsum board installation

Documents
Dimensional drawing (technical document available for product ALR09)

Available finishes
S | Satin with polished detail

Lega a ridotto contenuto di carbonio, universalmente riconosciuta per le caratteristiche di igiene e ottima resistenza alla corrosione, particolarmente indicata anche per ambienti outdoor. Grazie alla sua composizione chimica, l’acciaio inossidabile non ossida e non arrugginisce a contatto con agenti esterni quali acqua e aria. Il film protettivo naturale di cui l’acciaio inossidabile è dotato, rende il materiale resistente nel tempo e sempre ripristinabile. I prodotti CEA sono interamente realizzati con l’ausilio di procedimenti meccanici che mantengono inalterate le caratteristiche di unicità e straordinarietà di questo materiale. L’acciaio inossidabile utilizzato per la produzione CEA, non viene trattato né con cromature né con galvaniche, conservando le proprietà di prodotto ecologico, eco-compatibile, totalmente riciclabile e altamente igienico.

Special finishes

• KD | Black Diamond
• Z | Bronze
• P | Copper
• X | Light Gold

The special finish treatments, produced on customer request, result from careful colour selection and technological development based on high‑thickness deposition of zirconium and graphite powder blends. Through an evaporation process in sealed (plasma) chambers these powders condense and solidify, making the stainless steel surface more resistant to cleaning agents and saline air and providing scratch resistance. In the Black Diamond version the surface also resists lime deposits thanks to a self‑lubricating characteristic that helps keep the product cleaner for longer. CEA special finishes enhance the stainless steel’s properties, increasing both shine and resistance. All CEA special finishes are ecological and biocompatible.
Colour variations or shading are not production defects but a characteristic of the finishing process that preserves the material’s biocompatibility and ecological nature. Chromatic shifts, perceived as tone gradations, may occur due to material oxygenation on contact with air, notably in BRONZE and COPPER finishes. The colour shift gives the product greater depth and a more natural effect.

Part number legend
Model | Item | Colour | Wood essence | Special finish | Finish
ZIQ | 02 | / | / | X | L
GIO | 25 | W | N | KD | S

S satin finish
L polished finish

Example 1
ZIQ 02 X L
Model: ZIQQ Item: 02 Special finish: X Light Gold Finish: L polished

Example 2
GIO 25 W N KD S
Model: GIOTTO Item: 25 Silicone colour: W White Wood: N Canaletto Walnut Special finish: KD Black Diamond Finish: S satin

Product variants

• ALR08
• ALR06
• ALR07

Technical specifications

• Model: ALR09
• Type: Deck-mounted mixer tap with double-action control
• Spout: wall‑swivel, L max 170 mm
• Aerator flow: 5 l/min (1.3 gpm)
• Equipment: auxiliary bracket for plasterboard / gypsum board
• Material: stainless steel (low carbon alloy), not chrome‑plated or galvanised
• Available finishes: satin with polished detail (S), polished (L)
• Special finishes on request: KD (Black Diamond), Z (Bronze), P (Copper), X (Light Gold)
