Aluminum balcony window FGP-V P50 APMX

pinewood-aluminumtop-hung

Overview
The FGP-V P50 APMX balcony window increases daylight, improves ventilation and creates a standing balcony recess in attic rooms. An integrated automatic air inlet provides continuous fresh air without excessive cooling. Interior: vacuum-impregnated pine with clear acrylic varnish. Exterior: anthracite aluminium cladding for enhanced weather resistance and a minimalist appearance.

Key points

• Glazing unit P50 — 44 mm triple-glazed unit; Uw 1.2 W/m²K standard, Uw 1.1 W/m²K with EHV-AT Thermo flashing
• Sound insulation Rw = 37 dB
• Integrated automatic air inlet for continuous fresh air
• Opens to form a balcony recess

Balcony window — product description
Designed for attic living spaces, the top-hung window provides wide opening for light and access to a balcony recess. The automatic air inlet regulates airflow according to external conditions to ensure comfort without drafts. The timber core delivers interior warmth while aluminium cladding ensures long-term durability.

Energy and acoustic efficiency
The 44 mm P50 glazing with thermoPro technology and a multi-chamber frame reduces thermal bridges and improves airtightness. Sound-insulating glass and an acoustic film deliver high acoustic performance (Rw = 37 dB), improving comfort in noisy contexts.

Aesthetics and durability
Vacuum-impregnated pine coated with clear acrylic varnish highlights the natural grain and fits modern interiors. Anthracite aluminium cladding (RAL 7016) provides a minimalist exterior finish; alternative colours available. FSC-certified wood and water-based coatings ensure responsible production.

Glazing and safety

• P50 glazing unit: 44 mm triple-glazed assembly with easy-clean outer coating
• Toughened outer pane for impact resistance
• Inner laminated P2A pane to reduce injury risk on breakage
• Acoustic film improves sound insulation
• Hail protection covered by lifetime warranty under applicable terms

Operation and ventilation
The window is top-hung and operated manually. The automatic air inlet adapts airflow to wind strength to limit gusts and noise while maintaining ventilation and indoor air quality.

Design and finish
Aluminium cladding developed with industrial design input emphasises a minimalist look. Standard exterior: anthracite (RAL 7016); alternatives: black (RAL 9005), grey-brown (RAL 7022). Interior finish: vacuum-impregnated pine with two coats of clear acrylic varnish.

Mandatory installation products
To achieve declared thermal and watertight performance use the recommended flashing for the installation. The dedicated EHV-AT Thermo flashing enables the Uw = 1.1 W/m²K result with the P50 glazing unit.

Instructions and documentation
Technical documentation and declarations are available for download, including product declaration for the P50 glazing unit and related technical files.

Technical specifications

• Commercial name: FGP-V P50 APMX
• Commercial size (W × H): 78 × 255 cm
• Window frame clear opening width: 688 mm
• Window frame clear opening height: 2456 mm
• Window sash clear opening width: 599 mm
• Window sash clear opening height: 1411 mm
• Window reveal clear opening width: 725 mm
• Window reveal clear opening height: 2489 mm
• Opening angle for cleaning: 180°
• Glazing unit: P50, 44 mm triple-glazed unit; easy-to-clean coating; toughened outer pane; inner P2A laminated pane; acoustic film
• Thermal transmittance Uw: 1.2 W/m²K (standard), 1.1 W/m²K (with EHV-AT Thermo flashing)
• Number of seals: 4
• Thermo technology: thermoPRO
• Airtightness class: Class 4
• Safety level / security system: topSafe
• Wind load resistance: Class C4/B4
• Impact resistance: Class 3 (450 mm)
• Watertightness: 9A
• Sound reduction index Rw: 37 dB; Ra1: 36 dB; Ra2: 34 dB
• Construction type: Balcony
• Window colour (interior): natural pine
• Cladding colour (exterior): Anthracite RAL 7016 (also available RAL 9005 and RAL 7022)
• Window material: Vacuum impregnated pinewood
• Cladding material: Aluminium
• Lacquer type: Acrylic; Number of lacquer coats: 2
• Opening method: Top hung
• Control system: Manual
• Solar power supply: No
• Automatic air inlet: Yes
• Handle model: GREENVIEW SILVER; Number of handles: 1
• Installation depth: N, V
• Installation location: Rafters
• Roof pitch (min.–max.): 30°–55°
• Product weight: 125 kg
• Package width: 0.8 m; Package length: 2.62 m; Package height: 0.205 m; Packaging method: Tied with transportation belts
