Commercial kitchen refrigerated counter PREMIER F 4 B DL DL DL DR L E CO2

4 doorswithout drawerfor frozen food

Product overview
The Premier F 4 B DL DL DL DR L E CO2 is a 4-Section Freezer Counter without controller for remote cooling system. Designed for built-in installation under an existing tabletop, it is supplied without worktop (insulated board included). The counter has four door sections, each fitted with two grey shelves, and external dimensions of W x D x H 2192 x 680 x 750–930 mm (height adjustable with legs/castors).

Key features

• Temperature stability: rapid recovery of internal temperature after door openings and defrost cycles.
• Seamless integration: front venting design eliminates need for airflow under, at the sides or at the back.
• Serviceability: extractable, compartmentalised cooling unit for simplified maintenance.
• Hygiene and efficiency: wide removable magnetic gaskets and triple-insulation zones to minimise cold air loss.
• Ergonomics: anti-tilt shelves, drawers with pull-out stops, extended telescopic drawer rails and full-length handles.
• Configuration options: multiple choices of doors, drawers, worktops, legs/castors/electric elevation and accessories.

More features (additional / optional)

• Soft Closing Drawer (optional).
• Alternative worktop options & insulated board versions.
• Increased body height option of 750 mm.
• Castor Extension Kit to raise castors by 50 mm (optional accessory).

Documentation (available)

• Declaration of conformity (CE) for remote counters.
• Instruction manual: Remote Counter User Manual (available in all languages).

Technical specifications

• Item number: 413031112102
• Model name: Premier F 4 B DL DL DL DR L E CO2
• Brand: Hoshizaki
• Warranty period: 1 Year on Parts
• Country of origin: Turkey
• Accessories included: 2 grey shelves per door section
• Product type: 4-Section Freezer Counter without controller for remote cooling system
• Equipped with: Without worktop (with insulated board) for built-in under existing tabletop, 4 door sections each with 2 grey shelves
• Ordering note: This freezer counter for connection to remote cooling system is on special order only; longer lead times to be considered
• Width: 2192 mm
• Width (packed): 2280 mm
• Depth: 680 mm
• Depth (packed): 820 mm
• Height: 750 mm
• Height including legs (minimum): 880 mm
• Height including legs (maximum): 930 mm
• Height (packed): 985 mm
• Volume (packed): 1.84 m³
• Number of shelves: 8
• Number of shelves per door section: 2
• Shelf size: 1/1 GN
• Min. cooling capacity F cabinets at -30°C: 376 W
• Temperature range span: -25 / +12 °C
• Climate class: 5 (max. ambient 40°C w/ 40% RH)
• Connection load: 650 W
• Exterior: Stainless steel AISI 304
• Interior: Stainless steel AISI 304
• Gross weight: 119 kg
• Net weight: 107 kg
• Insulation thickness: 60 mm
• Insulation type: Polyurethane
• Legs / Castors: H = 130-180 mm (L)
• Number of sections: 3 sections
• Power supply: 230 V, 50 Hz
• Maximum current amperage: 2.7 Ah
• Maximum system pressure: 90 Bar
• Volume, gross: 625 l
• Worktop options: Without worktop B
• Cooling system: For remote cooling system
• Configuration of sections: Models with door section
• Refrigerant compatibility: R744
• SKU: 413031112102
