Ceiling-mounted spotlight SASSO 140

surface-mountedLEDround

Quick info

• 2700 K, 3000 K, 3500 K, 4000 K
• CRI ≥ 90, 2 SDCM
• Up to 5120 lm | 128 lm/W
• L80 @ 50 000 h
• non DIM, DALI-2

Description
Cylindrical ceiling-mounted spotlight in aluminium with lacquered light inset and powder-coated housing. The luminaire housing attaches to the mounting plate without tools by interlock. Symmetric radiation characteristic ensured by a high-quality lens system; available with several beam angles. COB (Chip on Board) LED technology provides high flux with minimal multiple shadows. Driver integrated into the spotlight head. Designed for use in high rooms.

Colour

• white
• white/black
• white/gold
• white/matt silver
• black
• black/white
• black/gold
• black/matt silver

Availability
Available from Q2/27

Versions & Features

• Surface & suspended versions available
• High lumen output for high ceilings

Light distribution

• super spot
• spot
• medium
• flood
• wide flood

Technical specifications

• Model: SASSO 140
• Mounting: ceiling mounted (surface) — also available in suspended version
• Material: aluminium
• Surface finish: surface light inset lacquered; surface housing powder coated
• Attachment: luminaire housing can be attached to mounting plate without tools by interlock
• Optics: symmetric radiation characteristic; high quality lens system; available with different beam angles
• Light source: COB (Chip on Board) LED technology
• Colour temperature: 2700 K, 3000 K, 3500 K, 4000 K
• Colour rendering: CRI ≥ 90, 2 SDCM
• Light output: up to 5120 lm
• Efficiency: up to 128 lm/W
• Lumen maintenance: L80 @ 50 000 h
• Dimming / Control: non DIM or DALI-2 (depending on configuration)
• Integrated electronics: driver integrated into spotlight head
• Application: designed for use in high rooms
