Built-in spotlight MOVE IN

LEDroundIP20

Quickinfo
2700 K, 3000 K
CRI ≥ 90 / 2 SDCM or 3 SDCM
Up to 106 lm/W
L80 / 50,000 h; L85 / 50,000 h; L90 / 100,000 h
DALI-2 or non-DIM variants
Front protection: IP20


Description
Round recessed spotlight element in aluminium, offered in three nominal diameters. Available finishes: polished chrome, brushed aluminium or powder-coated colours. The luminaire installs without tools into a mounting set (trimless or with trim) using a ball catch system. A special mounting tool is available as an accessory for trimless housings.

The spotlight height is adjustable without tools: flush with the ceiling or extended by 25 mm or 35 mm. COB (Chip on Board) LED technology provides high luminous efficacy and a compact light source to minimize multiple shadows. The vapour-deposition coated, faceted aluminium reflector delivers a precise radiation characteristic and contributes to glare reduction through a recessed light point plane. A range of optical attachments is available as accessories for beam shaping.


Features / Use cases

• Round recessed spotlight element in aluminium
• Three nominal diameters: Ø22 mm, Ø32 mm, Ø45 mm (variants indicated on product page)
• Finishes: polished chrome, brushed aluminium, powder-coated (traffic white, jet black, etc.)
• Mounting: trimless or with trim; tool-free installation in mounting set with ball catch system
• Special mounting tool available for trimless installation
• Height adjustable without tools: flush, +25 mm or +35 mm
• Optical attachments / beam shaping accessories: spot, medium, flood, wallwasher, wall-floor optics
• COB LED technology for efficient, clean illumination with reduced shadowing
• Good glare control due to recessed light point plane and faceted reflector

Technical specifications

• Colour temperatures: 2700 K, 3000 K
• Colour rendering: CRI ≥ 90
• MacAdam initial tolerance: 2 SDCM (some variants), 3 SDCM (others)
• Photometric efficiency: up to 106 lm/W (variant dependent)
• Lumen maintenance: L80 / 50,000 h; L85 / 50,000 h; L90 / 100,000 h (variant dependent)
• Control options: DALI-2 compatible or non-DIM (variant dependent)
• Front protection / rating: IP20
• Materials: aluminium housing; vapour-deposition coated aluminium reflector with faceted design
• Optical characteristics: precise radiation pattern; available beam angles: spot, super spot, medium, flood, wallwasher/floor
• Mounting: tool-free installation in mounting set; trimless installation possible (special mounting tool accessory); ball catch system for trim mounting
• Height adjustment: tool-free, flush or +25 mm / +35 mm
• Finishes: chrome, brushed aluminium, traffic white, jet black, etc.
• Variants: multiple diameters and trim/trimless combinations (Ø22 / Ø32 / Ø45)
• Accessories: mounting set (matching colours), optical attachments, special trimless mounting tool
• Documentation and files: datasheets, CAD, IES/LDT photometric files, BIM/Revit and 3D outputs (variant-specific)
