Recessed downlight SASSO PRO 60

LEDroundindoor

Quickinfo
2700 K, 3000 K, 3500 K, 4000 K · CRI ≥ 90 · 2 SDCM · up to 1190 lm · 110 lm/W (up to 132 lm/W indicated) · L90 @ 50,000 h · non DIM, DALI-2

Description
Round recessed spotlight in die-cast aluminium designed for tool-free installation with a ball catch mounting set. Surface finish: raw or powder coated. Light module is rotatable and tiltable for flexible aiming. COB (Chip on Board) LED for high efficiency and narrow shadowing. Changeable optics and optical attachments available as accessories to adapt beam shape and distribution.

Features

• High-efficiency COB LEDs
• Glare control UGR ≤ 13
• 360° rotation and 35° tilt for precise aiming
• Interchangeable optics for spot/medium/flood/wide flood
• Tool-free installation and module exchange (ball catch system)
• Optical attachments available as accessories

Colour / Finishes

• traffic white
• jet black
• aluminium raw

Light distribution

• spot
• medium
• flood
• wide flood

Availability
Available from Q3/27

Technical specifications

• Model: SASSO PRO 60
• Luminous flux: up to 1190 lm
• Luminous efficacy: approx. 110 lm/W (document indicates up to 132 lm/W high efficiency)
• Correlated Colour Temperatures: 2700 K, 3000 K, 3500 K, 4000 K
• Colour Rendering Index: CRI ≥ 90
• Tolerance: 2 SDCM
• LED technology: COB (Chip on Board)
• Lumen maintenance: L90 @ 50,000 h
• Dimming options: non DIM, DALI-2
• Glare: UGR ≤ 13
• Mechanical: die-cast aluminium body; raw or powder coated finish; mounting set with ball catch system for tool-free installation
• Adjustability: 360° rotation, 35° tilt
• Optics: changeable optic; different beam angles for precise radiation characteristics
• Accessories: optical attachments available
