Recessed ceiling downlight SASSO PRO 80

semi-recessedLEDround

Quickinfo

• 3000 K, 3500 K, 4000 K
• CRI ≥ 90, CRI ≥ 98 / 2 SDCM (initial MacAdam), 3 SDCM (initial MacAdam)
• UGR ≤ 10, UGR ≤ 13, UGR ≤ 16
• up to 142 lm/W
• L80 / 50000 h
• DALI-2, non DIM
• front IP20

Description
Round recessed spotlight in die-cast aluminium; installation without tools in mounting set with ball catch system; surface powder coated; installation possible in different housings; light inset rotatable and tiltable; optionally with recessed lighting level; optical attachments as accessories; high quality lens system; precise radiation characteristics with different beam angles; COB (Chip on Board) technology for maximum efficiency; no multiple shadows; efficient LEDs with very good colour rendering

Standards & control

• DiiA® standards 251, 252, 253
• DALI-2 and non DIM control options

Mechanical / optical features

• Die-cast aluminium housing, surface powder coated
• Installation in mounting set with ball catch system (tool-free)
• Light inset rotatable 360° and tiltable 35°
• Optional recessed lighting level
• Optical attachments available as accessories
• High quality lens system, precise radiation characteristics

Light distribution

• Available beam types: super spot, spot, medium, flood, wide flood

Products and codes (excerpt)
New | X048-29B0017F 048-2996318 002-90766 | traffic white, jet black, flood, 3000 K, CRI ≥ 90, fixture 15.5 W, 124 lm/W | non DIM
New | X048-29B0017F 048-2996318 002-90767 | traffic white, jet black, flood, 3000 K, CRI ≥ 90, fixture 15.5 W, 124 lm/W | DALI-2
New | X048-29B0017F 048-2996318 002-90771 | traffic white, jet black, flood, 3000 K, CRI ≥ 90, fixture 10 W, 134 lm/W | non DIM
New | X048-29B0017F 048-2996318 002-90790 | traffic white, jet black, flood, 3000 K, CRI ≥ 90, fixture 10 W, 134 lm/W | DALI-2
New | X048-29B0017M 048-2996318 002-90766 | traffic white, jet black, medium, 3000 K, CRI ≥ 90, fixture 15.5 W, 120 lm/W | non DIM
New | X048-29B0017M 048-2996318 002-90771 | traffic white, jet black, medium, 3000 K, CRI ≥ 90, fixture 15.5 W, 120 lm/W | DALI-2
New | X048-29B0017M 048-2996318 002-90790 | traffic white, jet black, medium, 3000 K, CRI ≥ 90, fixture 15.5 W, 120 lm/W | DALI-2
New | X048-29B0017N 048-2996318 002-90771 | traffic white, jet black, narrow spot, 3000 K, CRI ≥ 90, fixture 11.8 W, 78 lm/W | non DIM
New | X048-29B0017N 048-2996318 002-90790 | traffic white, jet black, narrow spot, 3000 K, CRI ≥ 90, fixture 11.8 W, 78 lm/W | DALI-2
New | X048-29B0017S 048-2996318 002-90771 | traffic white, jet black, spot, 3000 K, CRI ≥ 90, fixture 10.4 W, 104 lm/W | non DIM

Technical specifications

• Model / series: SASSO PRO 80
• Housing: die-cast aluminium, powder coated
• Mounting: mounting set with ball catch system (tool-free)
• Installation: possible in different housings; optional recessed lighting level
• Light source: COB (Chip on Board) LED technology
• Colour temperatures: 3000 K, 3500 K, 4000 K
• Colour rendering: CRI ≥ 90 and CRI ≥ 98 variants
• MacAdam: 2 SDCM (for CRI ≥ 98 variants), 3 SDCM
• UGR classes available: ≤ 10, ≤ 13, ≤ 16
• Efficiency: up to 142 lm/W (model dependent)
• Lumen maintenance: L80 / 50,000 h
• Control options: DALI-2 or non DIM
• Front protection: IP20
• Rotation / tilt: 360° rotatable, 35° tiltable
• Optical: high-quality lens system, precise radiation characteristics, no multiple shadows
• Accessories: optical attachments available
• Standards: DiiA® standards 251, 252, 253
