Recessed ceiling downlight SPIO 60

LEDroundIP20

Quickinfo

• 2700 K, 3000 K
• CRI ≥ 90 / 3 SDCM (initial MacAdam)
• UGR ≤ 10
• up to 63 lm/W
• L85 / 50000 h, L95 / 50000 h
• DALI-2, non DIM
• front IP20

Description
Round recessed spotlight in die-cast aluminium designed for a discreet ceiling appearance. Tool-free insertion into the mounting set using a ball catch system or magnetic attachment. Suitable for trimless installation in plasterboard ceilings with a paintable cover; the shadow joint between cover and mounting set can be filled. Available with trim or trimless versions. Choice of adjustable or fixed symmetric radiation characteristic. High-quality lens system provides precise light control while minimizing visible aperture (Ø 13 mm) to maintain a clean ceiling plane and avoid multiple shadows. Efficient LEDs with very good colour rendering ensure accurate colour reproduction.

Features

• Round recessed housing in die-cast aluminium
• Tool-free installation in mounting set with ball catch system or magnetic attachment
• Trimless installation option for plasterboard ceilings; paintable cover
• Shadow joint between cover and mounting set optionally fillable
• Available with trim or trimless
• Adjustable or fixed symmetric radiation characteristic
• High-quality LFO lens technology / lens system for precise light control
• Reduced light-emitting surface (Ø 13 mm) — 13 mm light output area
• No multiple shadows
• Efficient LEDs with very good colour rendering (CRI ≥ 90)
• Control options: DALI-2 or non DIM

Variants / Mounting options

• Downlight trim (white, black)
• Downlight trimless
• Adjustable trim (white, black)
• Adjustable trimless
• Multiple article variants with different optics (flood, wide flood) and color temperatures

Technical specifications

• Colour temperature: 2700 K or 3000 K
• Colour rendering: CRI ≥ 90 (initial MacAdam 3 SDCM)
• Unified Glare Rating: UGR ≤ 10
• System efficacy: up to 63 lm/W (depending on variant)
• Lumen maintenance: L85 / 50000 h and L95 / 50000 h (variants)
• Control: DALI-2 or non DIM (variant dependent)
• Ingress protection (front): IP20
• Light-emitting surface diameter: 13 mm
• Mounting: trim or trimless; mounting set with ball catch or magnetic attachment; trimless suitable for plasterboard ceilings; paintable cover
• Optics: high quality lens system (LFO lens technology) with options such as flood and wide flood
