Recessed spotlight MOVE IN

LEDroundtubular

Quickinfo

• Colour temperature: 2700 K, 3000 K
• CRI ≥ 90 / initial colour consistency: 2 SDCM or 3 SDCM (variant dependent)
• System efficacy: up to 106 lm/W
• Lumen maintenance: L80 / 50,000 h; L85 / 50,000 h; L90 / 100,000 h
• Control: DALI-2 or non-dimmable
• Front protection: IP20

Description
Round recessed spotlight element in aluminium, available in three sizes (Ø22, Ø32, Ø45). Finishes: polished chrome, brushed aluminium or powder coated. Tool-free installation in the mounting set (trimless or with trim) using a ball-catch system; a dedicated mounting tool for trimless housing is available as an accessory. Spotlight element height adjustable without tools: flush with the ceiling, or extended +25 mm or +35 mm. The spotlight head rotates 360° and tilts 90°. COB (Chip on Board) LED technology delivers high efficacy and reduced multiple shadows. Aluminium reflector with vapour-deposition coating and faceted design provides precise radiation characteristics. Recessed light point plane improves glare control. Optical attachments and mounting accessories available.

Features

• Tool-free height adjustment: flush, +25 mm, +35 mm
• Spotlight head: 360° rotation and 90° tilt
• COB LED technology for high efficiency and reduced multiple shadows
• Aluminium reflector with vapour-deposition coating and faceted design for precise beam
• Reduced glare due to recessed light point plane
• Tool-free installation in mounting set (trim or trimless) with ball-catch system
• Special mounting tool available as accessory for trimless installation
• Optical attachments available as accessories

Colour & mounting options

• Finishes: polished chrome, brushed aluminium, powder coated
• Mounting set: trim or trimless; mounting set colours include traffic white and jet black depending on configuration

Light distribution

• Available beam options: spot, medium, flood, super spot (multiple beam angles available)

Technical specifications

• Colour temperatures: 2700 K, 3000 K
• CRI: ≥ 90
• Initial colour consistency: 2 SDCM or 3 SDCM (variant dependent)
• System efficacy: up to 106 lm/W (configuration dependent)
• Lumen maintenance: L80 / 50,000 h; L85 / 50,000 h; L90 / 100,000 h
• Control options: DALI-2 or non-dimmable
• Front protection rating: IP20
• LED technology: COB (Chip on Board)
• Materials: aluminium housing and vapour-deposition coated aluminium reflector with faceted design
• Glare control: recessed light point plane
• Mounting: tool-free installation in mounting set (trim or trimless) with ball-catch system; special mounting tool for trimless available
• Mechanical adjustment: tool-free height adjustment, 360° rotation, 90° tilt
• Available sizes: Ø22, Ø32, Ø45 variants
• Accessories: mounting sets, optical attachments and dedicated mounting tools available
